Beckhoff EtherCAT Terminal, 2-channel digital input, 24 V DC, 1 µs EL1202
The EL1202 digital input terminal acquires the binary 24 V control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation unit. The EtherCAT Terminal contains two channels whose signal state is
| Approvals/markings | CE, CCC, UL, ATEX, IECEx |
|---|---|
| Configuration | no address or configuration setting |
| Connection technology | 4-wire |
| Current consumption E-bus | typ. 110 mA |
| Current consumption power contacts | typ. 6 mA + load |
| Distributed clock accuracy | << 1 µs |
| Distributed clocks | can be activated, see documentation |
| Electrical isolation | 500 V (E-bus/field potential) |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Ex marking | ATEX: II 3 G Ex ec IIC T4 Gc IECEx: Ex ec IIC T4 Gc |
| Input current | typ. 3 mA (similar to EN 61131-2, type 3) |
| Input delay TON/TOFF | < 1 µs |
| Input filter | typ. < 1 µs |
| Nominal Voltage | 24 V DC (-15%/+20%) |
| Number of inputs | 2 |
| Operating Temperature | -25…+60°C |
| Pluggable wiring level | for all ESxxxx terminals |
| Protect. rating/installation pos. | IP20/variable |
| Relative Humidity | 95%, no condensation |
| Signal voltage “0” | -3…+5 V (similar to EN 61131-2, type 3) |
| Signal voltage “1” | 11…30 V (similar to EN 61131-2, type 3) |
| Special Features | DC can be activated, see documentation |
| Specification | similar to EN 61131-2, type 3, “0”: -3…5 V DC, “1”: 11…30 V DC, typ. 3 mA input current |
| Storage Temperature | -40…+85°C |
| Timestamp accuracy in the terminal | 10 ns (+ input delay) |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| Weight | approx. 55 g |
