Beckhoff EtherCAT Terminal, 4-channel digital input, 48 V DC, 10 µs EL1134
The EL1134 digital input terminal acquires the binary 48 V control signals from the process level and transmits them, in an electrically isolated form, to the higher-level automation unit. The EtherCAT Terminal has four channels that indicate their
| “0” signal voltage | < 10 V (EN 61131-2, type 1) |
|---|---|
| “1” signal voltage | > 34 V (EN 61131-2, type 1) |
| Approvals/markings | CE, CCC, UL, ATEX, IECEx |
| Configuration | no address or configuration setting |
| Connection technology | 2-/3-wire |
| Current consumption E-bus | typ. 90 mA |
| Current consumption power contacts | typ. 10 mA + load |
| Distributed clocks | – |
| Electrical isolation | 500 V (E-bus/field potential) |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Ex marking | ATEX: II 3 G Ex ec IIC T4 Gc IECEx: Ex ec IIC T4 Gc |
| Input current | typ. 3 mA (EN 61131-2, type 1) |
| Input filter | typ. 10 µs |
| Nominal Voltage | 48 V DC |
| Number of inputs | 4 |
| Operating Temperature | -25…+60°C |
| Pluggable wiring level | for all ESxxxx terminals |
| Protect. rating/installation pos. | IP20/variable |
| Relative Humidity | 95%, no condensation |
| Storage Temperature | -40…+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| Weight | approx. 55 g |
