Schunk ERT 12-40-B-N-L-N
| Axial run-out [mm] | 0.02 |
|---|---|
| Encoder system | Encoder (absolute) |
| Force Fx max. [N] | 700.0 |
| Force Fz max. [N] | 700.0 |
| Height Z [mm] | 64.0 |
| Intermediate circuit voltage [V] | 560.0 |
| IP protection class | 40 |
| Length X [mm] | 181.0 |
| Max. ambient temperature [°C] | 40.0 |
| Max. current [A] | 3.27 |
| Max. permissible mass moment of inertia [kgm²] | 0.07 |
| Max. rotational speed [1/min] | 600.0 |
| Min. ambient temperature [°C] | 5.0 |
| Moment holding brake [Nm] | 1.4 |
| Moment My max. [Nm] | 24.0 |
| Nominal current [A] | 0.96 |
| Nominal torque [Nm] | 1.4 |
| Output signal | HIPERFACE DSL® |
| Peak torque [Nm] | 4.17 |
| Repeat accuracy | 0.01 |
| Run-out accuracy [mm] | 0.02 |
| SIL certification | not certified |
| Weight (Kg) | 2.7 |
| Width Y [mm] | 135.0 |
Frequently Asked Questions
How do I get pricing for 1529440?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 1529440?
1529440 is a Schunk part. KKM Solutions sources Schunk components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 1529440?
Key specifications include Axial run-out [mm]: 0.02; Encoder system: Encoder (absolute); Force Fx max. [N]: 700.0; Force Fz max. [N]: 700.0. The full specification table on this page lists every published attribute for this part.
How quickly can 1529440 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
