084Z4035 — Danfoss Temperature transmitter, MBT 3560, 50 mm, G, 1/4
KKM Solutions is an independent parts distributor, not an authorized Danfoss dealer — how we source.
Danfoss 084Z4035 - MBT 3560 - Electrical connection: Angular connector; Type: MBT 3560; Gross weight: 0.174 Kilogram.
Overview
Part number 084Z4035 from Danfoss, listed in Temperature Sensors. Specifications on file: Ambient temperature max. [°C] 85 °C; Ambient temperature max. [°F] 185 °F; Approval CE; CE evaluated Yes. KKM Solutions quotes this part with pricing and availability confirmed per order.
Danfoss 084Z4035 is an MBT 3560 catalog item from Danfoss. The manufacturer's published data for this part number specifies Electrical connection: Angular connector and Type: MBT 3560.
The specification set recorded for this part number covers Gross weight: 0.174 Kilogram; Net weight: 0.118 Kilogram; Volume: 0.577 Liter; EAN: 5702423197446; Product group: Sensors; Product Name Description: Temperature transmitter; China RoHS compliance: Out of scope; Connection standard: ISO 228; Connection type: G; Contains batteries: No; EU RoHS compliance: Yes with exemptions; Packing format: Multi pack. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Ambient temperature max. [°C] | 85 °C |
|---|---|
| Ambient temperature max. [°F] | 185 °F |
| Approval | CE |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Connection material | Stainless steel |
| Connection standard | ISO 228 |
| Connection type | G |
| Contains batteries | No |
| EAN | 5702423197446 |
| Electrical conn. Male/Female | Male and Female |
| Electrical connection | Angular connector |
| Electrical connection size | Pg 9 |
| Electrical connection standard | EN 175301-803-A |
| Enclosure rating IP | IP65 |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Extension length [in] | 1.3 in |
| Extension length [mm] | 33 mm |
| Gross weight | 0.174 Kilogram |
| In scope of WEEE | Yes |
| Insertion length [in] | 1.97 in |
| Insertion length [mm] | 50 mm |
| Insertion type | FIXED |
| Measuring range [°C] [Max] | 200 °C |
| Measuring range [°C] [Min] | 0 °C |
| Measuring range [°F] [Max] | 392 °F |
| Measuring range [°F] [Min] | 32 °F |
| Net weight | 0.118 Kilogram |
| Output signal [mA] [Max] | 20 mA |
| Output signal [mA] [Min] | 4 mA |
| Packing format | Multi pack |
| Process connection Male/Female | Male |
| Process connection material | Stainless steel |
| Process Connection Size | 1/4 |
| Process connection standard | ISO 228-1-A |
| Process Connection Type | G |
| Product group | Sensors |
| Product Name Description | Temperature transmitter |
| Protection tube diameter [in] | 0.315 in |
| Protection tube diameter [mm] | 8 mm |
| Protection tube material | AISI 316 TI |
| Quantity per packing format | 13 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | 8127e7d9-3431-4421-a02a-bab746bc2e4f |
| SCIP dossier product name | Sensor MBT 3560 |
| Sensor elem. resistance [Ohm] | 1000 Ohm |
| Sensor element type | Pt |
| Sensor Insert | FIXED |
| Supply voltage [V] DC [max] | 32 V |
| Supply voltage [V] DC [min] | 10 V |
| Temperature range [°C] [Max] | 200 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 392 °F |
| Temperature range [°F] [Min] | -58 °F |
| Transmitter setting range [°C] [Max] | 200 °C |
| Transmitter setting range [°C] [Min] | 0 °C |
| Transmitter setting range [°F] [Max] | 392 °F |
| Transmitter setting range [°F] [Min] | 32 °F |
| Transmitter type | Integrated |
| Type | MBT 3560 |
| Type designation | MBT 3560-0001-0050-10-120 |
| Volume | 0.577 Liter |
Product details
| Manufacturer | Danfoss |
|---|---|
| Manufacturer part number | 084Z4035 |
| Product category | Temperature Sensors |
| Published specifications | 63 attributes listed |
| Related part numbers | 15 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for 084Z4035?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 084Z4035?
084Z4035 is made by Danfoss and is listed in our Temperature Sensors category. KKM Solutions is an independent distributor, not an authorized Danfoss dealer: we source the exact Danfoss part number 084Z4035, and the quote confirms condition and lead time before you order.
Is the 084Z4035 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the 084Z4035, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of 084Z4035?
No published lifecycle status is on file for 084Z4035. Danfoss lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of 084Z4035?
Key specifications include Ambient temperature max. [°C]: 85 °C; Ambient temperature max. [°F]: 185 °F; Approval: CE; CE evaluated: Yes. The full specification table on this page lists every published attribute for this part.
What voltage does 084Z4035 use?
Per the published specification for 084Z4035: Supply voltage [V] DC [max]: 32 V; Supply voltage [V] DC [min]: 10 V. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What is the IP rating of 084Z4035?
Per the published specification for 084Z4035: Enclosure rating IP: IP65. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What thread or connection does 084Z4035 use?
Per the published specification for 084Z4035: Connection type: G; Process Connection Size: 1/4. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can 084Z4035 ship?
Lead time for 084Z4035 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
