1762-IQ8 Allen-Bradley US
Allen-Bradley 1762-IQ8 - PLCs & I/O - Width: 40.4 mm; Height: 90 mm; Weight: 200 g.
Overview
In our catalog, the 1762-IQ8 from Allen-Bradley is listed under the PLCs & I/O category. The manufacturer's published data for this part number specifies Width: 40.4 mm and Height: 90 mm.
Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak, 2 hr per axis Relay ops : 1.5G
Key manufacturer data on file for this item includes Weight: 200 g; Operating Temperature: -20 to 65 °C; Depth: 87; Altitude: 2000 m; Class: Progmable Logic Controller; Number of digital inputs: 8; Shock: Operating: 30G panel mounted, 3 pulses per axis, Relay ops: 7G; Number Of Channels: 8 Point; Temperature Rating: 0…55 °C (32…131 °F); Conducted RF immunity: IEC 1000-4-6: 10V @ 0.15...80MHz; EFT/B immunity: IEC1000-4-4: 2kV @ 5kHz; ESD immunity: IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Altitude | 2000 m |
|---|---|
| Bus current draw, max | 50mA @ 5V DC (0.25 W) |
| Class | Progmable Logic Controller |
| Conducted RF immunity | IEC 1000-4-6: 10V @ 0.15...80MHz |
| Depth | 87 |
| digital input modules | 8 Point 24V DC Sink/Source Input Module |
| Digital inputs configurable | False |
| Digital outputs configurable | False |
| EFT/B immunity | IEC1000-4-4: 2kV @ 5kHz |
| ESD immunity | IEC1000-4-2: 4kV contact, 8kV air, 4kV indirect |
| Estimated Lead Time | 5 days |
| Hazardous environment class | Hazardous Location, Class I, Division 2 Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213) |
| Heat dissipation, max | 3.7 W |
| Height | 90 mm |
| I/O Isolation | Isolated |
| I/O Status Indication | LED |
| IEC input compatibility | Type 1+ |
| Input group to backplane isolation | Verified by one of the following dielectric tests: 1200V AC @ 1s or 1697V DC @ 1s, 75V DC working voltage (IEC Class 2 reinforced insulation) |
| Isolated groups | Group 1: inputs 0...7 (internally connected commons) |
| Module Interfaces | Digital |
| Nominal Impedance | 3 kΩ |
| Number Of Channels | 8 Point |
| Number of commons | 1 |
| Number of digital inputs | 8 |
| Off-state current, max | 1.5 mA |
| Off-state voltage, max | 5V DC |
| ON-state current, max | 12.0mA @ 30V DC |
| On-state current, min | 2.0mA @ 10V DC |
| On-state current, nom | 8.0mA @ 24V DC |
| On-state voltage, min | 10V DC |
| Operating humidity | 5...95% noncondensing |
| Operating Temperature | -20 to 65 °C |
| Operating voltage | 10…30V DC @ 30°C (86 °F) 10…26.4V DC @ 55°C (131 °F) |
| Power supply distance rating | 6 (the module may not be more than 6 modules away from the system power supply) |
| Radiated and conducted emissions | EN50081-2: Class A |
| Radiated RF immunity | IEC1000-4-3: 10 V/m, 80...1,000 MHz, 80% Alitude modulation, +900 MHz keyed carrier |
| Redundancy | False |
| Shock | Operating: 30G panel mounted, 3 pulses per axis, Relay ops: 7G |
| Short-circuit protection, outputs available | False |
| Signal delay | On delay: 8.0 ms |
| Standard Warranty Duration | 1 year |
| Storage temperature, min | -40 °C |
| Suitable for safety functions | False |
| Surge transient immunity | IEC1000-4-5: 2 kV common mode, 1 kV differential mode |
| Temperature Rating | 0…55 °C (32…131 °F) |
| Time delay at signal exchange | 8 ms |
| Type of electric connection | Screw connection |
| Type of voltage (input voltage) | DC |
| UPC | 612598207206 |
| Vibration | Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak, 2 hr per axis Relay ops : 1.5G |
| Voltage category | 24V DC sink/source |
| Weight | 200 g |
| Width | 40.4 mm |
Product details
| Manufacturer | Allen-Bradley |
|---|---|
| Manufacturer part number | 1762-IQ8 |
| Product category | PLC CPUs & Systems |
| Country of origin | Malaysia |
| Published specifications | 53 attributes listed |
| Related part numbers | 16 other part numbers in this family |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does 1762-IQ8 cost?
1762-IQ8 is available for direct purchase at CA$263.29 (CAD), shown on this page with an Add to Cart button. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the 1762-IQ8?
1762-IQ8 is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What is the lifecycle status of 1762-IQ8?
We do not hold a published lifecycle status for 1762-IQ8. Allen-Bradley's publishes whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the current status with the manufacturer at quote time — you are told if the part is superseded or discontinued before you commit. Either way we source current-production, superseded and long-obsolete parts the same way; where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 1762-IQ8?
Key specifications include Altitude: 2000 m; Bus current draw, max: 50mA @ 5V DC (0.25 W); Class: Progmable Logic Controller; Conducted RF immunity: IEC 1000-4-6: 10V @ 0.15...80MHz. The full specification table on this page lists every published attribute for this part.
How quickly can 1762-IQ8 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
