1762-IF4 Allen-Bradley MicroLogix 4-Ch Current/Voltage Analog Input Module
Allen-Bradley 1762-IF4 - I/O Modules & Remote I/O - Width: 40 mm; Height: 90 mm; Weight: Shipping: 240 g (0.53 lbs.) approximately (with cartoon).
Overview
Allen-Bradley 1762-IF4 — I/O Modules & Remote I/O. Specs: Width: 40 mm · Height: 90 mm · Weight: Shipping: 240 g (0.53 lbs.) approximately (with cartoon) · Operating Temperature: -20 °C · Storage Temperature: -40 °C · Class: Progmable Logic Controller · Shock: Operating: 30 g · Vibration: Operating: 5 g @ 10...500 Hz, 0.030 in. max. peak-to-peak. Quoted per order by KKM Solutions.
Specifications
| A/D converter type | Successive approximation |
|---|---|
| analog input modules | 4 Channel Current/Voltage Analog Input Module |
| Analog normal operating range | Voltage: -10...10V DC |
| Analogue inputs configurable | True |
| Analogue outputs configurable | False |
| Bus current draw, max | 40mA @ 5V DC, 50mA @ 24V DC |
| Channel diagnostics | Over or under range or open circuit condition by bit reporting for analog inputs |
| Class | Progmable Logic Controller |
| Common mode rejection | >55 dB at 50 and 60 Hz |
| Common mode voltage range | -27 to 27V |
| Conducted immunity | 10V @ 0.15...80MHz |
| Current input protection | -32 mA |
| Current Range | 4-20 |
| Depth | 87 |
| ESD immunity | EN 61000-4-2, 4 kV contact, 8 kV air, 4 kV indirect |
| Estimated Lead Time | 5 days |
| Fast transient burst | IEC1000-4-4: 2kV @ 5kHz |
| Full scale analog ranges | Voltage: -10.5...10.5V DC, Current: -21...21 mA |
| Hazardous environment class | Hazardous Location, Class I, Division 2 Groups A, B, C, D (UL 1604, C-UL under CSA C22.2 No. 213) |
| Height | 90 mm |
| I/O Isolation | Isolated |
| I/O Status Indication | LED |
| Input and output group to system isolation | 30V AC/30V DC rated working voltage (N.E.C. Class 2 required) (IEC Class 2 reinforced insulation) type test: 500V AC or 707V DC @ 1min |
| Input impedance | Voltage Terminal: 200 KΩ |
| Input signal, configurable | True |
| Input update time | Typical: 130, 250, 290, 450, 530 ms (selectable) |
| Input, resistance thermometer | False |
| Input, resistor | False |
| Input, thermocouple | False |
| Module Interfaces | Analog input |
| Module power LED | On: indicates power is applied |
| Non-linearity | ±0.12% (in % full scale) |
| Number Of Channels | 4 point |
| Number of inputs | 4 differential (bipolar) |
| Operating altitude | 2000 m |
| Operating humidity | 5...95% noncondensing |
| Operating Temperature | -20 °C |
| Output signal configurable | False |
| Radiated and conducted emissions | EN50081-2: Class A |
| Radiated immunity | IEC1000-4-3: 10 V/m, 80...1,000 MHz, 80% Alitude modulation, +900 MHz keyed carrier |
| Recommended cable | Belden 8761 (shielded), (For 1762-IT4, shielded thermocouple extension wire for the specific type of thermocouple you are using. Follow thermocouple manufacturer’s recommendations.) |
| Repeatability | -0.12 to 0.12% |
| Resolution of the analogue inputs | 15 bit |
| Shock | Operating: 30 g |
| Standard Warranty Duration | 1 year |
| Storage Temperature | -40 °C |
| Surge immunity | IEC1000-4-5: 1kV galvanic gun |
| Temperature Rating | -20…65 °C (-4…149 °F) |
| Type of electric connection | Screw connection |
| Typical overall accuracy | ±0.32% full scale @ -20...65 °C, ±0.24% full scale @ 25 °C |
| UPC | 611320152128 |
| Vibration | Operating: 5 g @ 10...500 Hz, 0.030 in. max. peak-to-peak |
| Voltage input protection | -30 V |
| Weight | Shipping: 240 g (0.53 lbs.) approximately (with cartoon) |
| Width | 40 mm |
Product details
| Manufacturer | Allen-Bradley |
|---|---|
| Manufacturer part number | 1762-IF4 |
| KKM catalog reference | Allen-Bradley-1762-IF4 |
| Product category | I/O Modules & Remote I/O |
| Country of origin | Malaysia |
| Published specifications | 55 attributes listed |
| Related part numbers | 16 other part numbers in this family |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does 1762-IF4 cost?
1762-IF4 is listed at CA$524.11 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the 1762-IF4?
1762-IF4 is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What is the lifecycle status of 1762-IF4?
We do not hold a published lifecycle status for 1762-IF4. Allen-Bradley's publishes whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the current status with the manufacturer at quote time — you are told if the part is superseded or discontinued before you commit. Either way we source current-production, superseded and long-obsolete parts the same way; where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 1762-IF4?
Key specifications include A/D converter type: Successive approximation; analog input modules: 4 Channel Current/Voltage Analog Input Module; Analog normal operating range: Voltage: -10...10V DC; Analogue inputs configurable: True. The full specification table on this page lists every published attribute for this part.
How quickly can 1762-IF4 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
