Schunk TCU-P-050-3-OV
Schunk 324757 - Compensation units - Weight (Kg): 0.1; Min. ambient temperature [°C]: -10.0; Max. ambient temperature [°C]: 90.0.
The Schunk 324757 is part of the Compensation units range in our industrial catalog. The manufacturer's published data for this part number specifies Weight (Kg): 0.1 and Min. ambient temperature [°C]: -10.0.
The specification set recorded for this part number covers Max. ambient temperature [°C]: 90.0; Length X [mm]: 30.0; Width Y [mm]: 42.0; Moment Mx max. [Nm]: 15.0; Moment My max. [Nm]: 5.0; Moment Mz max. [Nm]: 15.0; Locking: Without locking; Direct connection to*: PGN-plus 50; Max. force Fd [N]: 500.0; Hardness of the elastomer [Shore]: 68.0; Deflection X [°]: ± 1; Deflection Y [°]: ± 1. The complete technical table is shown in the Specifications tab on this page.
| Deflection X [°] | ± 1 |
|---|---|
| Deflection Y [°] | ± 1 |
| Deflection Z [°] | ± 1.5 |
| Direct connection to* | PGN-plus 50 |
| Hardness of the elastomer [Shore] | 68.0 |
| Length X [mm] | 30.0 |
| Locking | Without locking |
| Max. ambient temperature [°C] | 90.0 |
| Max. force Fd [N] | 500.0 |
| Min. ambient temperature [°C] | -10.0 |
| Moment Mx max. [Nm] | 15.0 |
| Moment My max. [Nm] | 5.0 |
| Moment Mz max. [Nm] | 15.0 |
| Weight (Kg) | 0.1 |
| Width Y [mm] | 42.0 |
Frequently Asked Questions
How do I get pricing for 324757?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 324757?
324757 is a Schunk part. KKM Solutions sources Schunk components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 324757?
Key specifications include Deflection X [°]: ± 1; Deflection Y [°]: ± 1; Deflection Z [°]: ± 1.5; Direct connection to*: PGN-plus 50. The full specification table on this page lists every published attribute for this part.
How quickly can 324757 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
