1351490 — Schunk EMH-RP 045-B
KKM Solutions is an independent parts distributor, not an authorized Schunk dealer — how we source.
Schunk 1351490 - Magnetic Gripper - Weight (Kg): 1.5; IP protection class: 52; Min. ambient temperature [°C]: 5.0.
Overview
Part number 1351490 from Schunk, listed in Pneumatic Grippers. Specifications on file: Activation time [ms] 300.0; Controller electronics integrated; Height Z [mm] 128.0; Holding force [N] 1360.0. KKM Solutions quotes this part with pricing and availability confirmed per order.
Schunk 1351490 is a Magnetic Gripper catalog item from Schunk. The manufacturer's published data for this part number specifies Weight (Kg): 1.5 and IP protection class: 52.
Key manufacturer data on file for this item includes Min. ambient temperature [°C]: 5.0; Max. ambient temperature [°C]: 50.0; Length X [mm]: 64.0; Width Y [mm]: 64.0; Height Z [mm]: 128.0; Controller electronics: integrated; Nominal voltage [V]: 24.0; Magnet area [cm²]: 10.75; Payload for horizontal magnet surface [kg]: 22.5; Payload for vertical magnet surface [kg]: 9.0; Module temperature increasement in case of 5 activations/minute [°C]: 11.0; Module temperature increasement in case of 15 activations/minute [°C]: 28.0. See the Specifications tab on this page for the full technical table.
Specifications
| Activation time [ms] | 300.0 |
|---|---|
| Controller electronics | integrated |
| Height Z [mm] | 128.0 |
| Holding force [N] | 1360.0 |
| IP protection class | 52 |
| Length X [mm] | 64.0 |
| Magnet area [cm²] | 10.75 |
| Max. ambient temperature [°C] | 50.0 |
| Max. current power [A] | 3.8 |
| Min. ambient temperature [°C] | 5.0 |
| Module temperature increasement in case of 15 activations/minute [°C] | 28.0 |
| Module temperature increasement in case of 5 activations/minute [°C] | 11.0 |
| Nominal voltage [V] | 24.0 |
| Payload for horizontal magnet surface [kg] | 22.5 |
| Payload for vertical magnet surface [kg] | 9.0 |
| Rated current logic [A] | 0.15 |
| Type of voltage | DC |
| Width Y [mm] | 64.0 |
Product details
| Manufacturer | Schunk |
|---|---|
| Manufacturer part number | 1351490 |
| Product category | Pneumatic Grippers |
| Published specifications | 18 attributes listed |
| Related part numbers | 3 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for 1351490?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 1351490?
1351490 is made by Schunk and is listed in our Pneumatic Grippers category. KKM Solutions is an independent distributor, not an authorized Schunk dealer: we source the exact Schunk part number 1351490, and the quote confirms condition and lead time before you order.
Is the 1351490 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the 1351490, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of 1351490?
No published lifecycle status is on file for 1351490. Schunk lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of 1351490?
Key specifications include Activation time [ms]: 300.0; Controller electronics: integrated; Height Z [mm]: 128.0; Holding force [N]: 1360.0. The full specification table on this page lists every published attribute for this part.
What voltage does 1351490 use?
Per the published specification for 1351490: Nominal voltage [V]: 24.0; Type of voltage: DC. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What is the current rating of 1351490?
Per the published specification for 1351490: Rated current logic [A]: 0.15. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What operating temperature is 1351490 rated for?
Per the published specification for 1351490: Max. ambient temperature [°C]: 50.0; Min. ambient temperature [°C]: 5.0. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can 1351490 ship?
Lead time for 1351490 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
