IFM O7H208 - Diffuse reflection sensors with background suppression - Material: housing: PA; Ambient temperature: -25...60.
Overview
Part number O7H208 from IFM, listed in Photoelectric Sensors. Specifications on file: Ambient temperature -25...60; Background suppression available yes; Cable 0.2 m, PUR; 3 x 0.14 mm²; Current consumption 20; ((24 V)). KKM Solutions quotes this part with pricing and availability confirmed per order.
The IFM O7H208 is part of the Diffuse reflection sensors with background suppression range in our industrial catalog. The manufacturer's published data for this part number specifies Material: housing: PA.
Particularly small housing for use where space is restricted; For the reliable position detection in feeding and handling technology; Small light spot and narrow light cone for detecting of small objects; Precise background suppression; Visible red light for simple alignment
Key manufacturer data on file for this item includes Ambient temperature: -25...60; Connector: 1 x M8; coding: A; Contacts: 3; Locking: snap-fit; Tightening torque: 0.5; Protection class: III; Dimensions: 20.3 x 15 x 9; Application: For applications in robotics, assembly and handling technology; Product type: Diffuse reflection sensors with background suppression; Cable: 0.2 m, PUR; 3 x 0.14 mm²; Operating voltage: 10...30 DC; (UL - Class 2 source required); Current consumption: 20; ((24 V)); Reverse polarity protection: yes; Range: 5...50; (white paper 200 x 200 mm). The complete technical table is shown in the Specifications tab on this page.
Specifications
| Ambient temperature | -25...60 |
|---|---|
| Application | For applications in robotics, assembly and handling technology |
| Background suppression available | yes |
| Cable | 0.2 m, PUR; 3 x 0.14 mm² |
| Connector | 1 x M8; coding: A; Contacts: 3; Locking: snap-fit |
| Current consumption | 20; ((24 V)) |
| Dimensions | 20.3 x 15 x 9 |
| Electrical design | NPN |
| Function principle | Diffuse reflection sensor |
| Housing | rectangular |
| Key Features | Particularly small housing for use where space is restricted; For the reliable position detection in feeding and handling technology; Small light spot and narrow light cone for detecting of small objects; Precise background suppression; Visible red light for simple alignment |
| Lens alignment | Side sensing |
| Light spot dimensions refer to | at maximum range |
| Material | housing: PA |
| Max. light spot diameter | 2.5 |
| Max. voltage drop switching output DC | 2.5 |
| MTTF | 1610 |
| Operating voltage | 10...30 DC; (UL - Class 2 source required) |
| Output function | light-on mode |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output DC | 100 |
| Product type | Diffuse reflection sensors with background suppression |
| Protection | IP 65 |
| Protection class | III |
| Range | 5...50; (white paper 200 x 200 mm) |
| Range adjustable | no |
| Range on black object (6 % remission) | 7...46 |
| Range on grey object (18 % remission) | 6...48 |
| Range on white object (90 % remission) | 5...50 |
| Reverse polarity protection | yes |
| Short circuit protection | yes |
| Special Feature | Background suppression |
| Specification Summary | Diffuse reflection sensor; red light; light-on mode; NPN; 50 mm; IP 65; 0.2 m PUR-Cable; M8 Connector |
| Switching frequency DC | 750 |
| Tightening torque | 0.5 |
| Type of light | red light |
| Type of short-circuit protection | yes (non-latching) |
| Wave length | 633 |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | O7H208 |
| Product category | Photoelectric Sensors |
| Published specifications | 38 attributes listed |
| Related part numbers | 13 other part numbers in this family |
