ifm OI5013 laser distance sensor
IFM OI5013 - Sensors - Material: housing: PPO modified; End cap: PBT; Ambient temperature: -25...80; Terminals: ...1.5 mm²; Cable sheath: Ø 7...13 mm.
This listing covers the IFM OI5013, a part number in the Sensors category. The manufacturer's published data for this part number specifies Material: housing: PPO modified; End cap: PBT and Ambient temperature: -25...80.
Diffuse reflection sensor; red light; light-on/dark-on mode; (configurable); PNP; 600 mm; IP 65; terminals: ...1,5 mm²; Cable sheath: Ø 7...13 mm
Key manufacturer data on file for this item includes Terminals: ...1.5 mm²; Cable sheath: Ø 7...13 mm; Dimensions: M30 x 1.5 / L = 125; Application: Industrial applications; Product type: Diffuse reflection sensor; Operating voltage: 10...55 DC; Current consumption: 10; ((24 V)); Reverse polarity protection: yes; Range: < 600; (white paper 200 x 200 mm 90 % remission); Overload protection: yes; Output function: light-on/dark-on mode; (configurable); Housing: Threaded type; Type of light: red light. The complete technical table is shown in the Specifications tab on this page.
| Ambient temperature | -25...80 |
|---|---|
| Application | Industrial applications |
| Current consumption | 10; ((24 V)) |
| Dimensions | M30 x 1.5 / L = 125 |
| Electrical design | PNP |
| Function principle | Diffuse reflection sensor |
| Housing | Threaded type |
| Material | housing: PPO modified; End cap: PBT |
| Max. voltage drop switching output DC | 2.5 |
| Operating voltage | 10...55 DC |
| Output function | light-on/dark-on mode; (configurable) |
| Overload protection | yes |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output DC | 250 |
| Product type | Diffuse reflection sensor |
| Protection | IP 65 |
| Range | < 600; (white paper 200 x 200 mm 90 % remission) |
| Range adjustable | yes |
| Reverse polarity protection | yes |
| Short circuit protection | yes |
| Specification Summary | Diffuse reflection sensor; red light; light-on/dark-on mode; (configurable); PNP; 600 mm; IP 65; terminals: ...1,5 mm²; Cable sheath: Ø 7...13 mm |
| Switching frequency DC | 40 |
| Terminals | ...1.5 mm²; Cable sheath: Ø 7...13 mm |
| Thread designation | M30 x 1.5 |
| Type of light | red light |
| Type of short-circuit protection | yes (non-latching) |
Frequently Asked Questions
How do I get pricing for OI5013?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the OI5013?
OI5013 is a IFM part. KKM Solutions sources IFM components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of OI5013?
Key specifications include Ambient temperature: -25...80; Application: Industrial applications; Current consumption: 10; ((24 V)); Dimensions: M30 x 1.5 / L = 125. The full specification table on this page lists every published attribute for this part.
How quickly can OI5013 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
