076G1023 — Danfoss Pressure transmitter, DST P310, -1 bar - 159 bar, -14.5 psi - 2306 psi
KKM Solutions is an independent parts distributor, not an authorized Danfoss dealer — how we source.
Danfoss 076G1023 - DST P310 - Electrical connection: Round Packard Metri-Pack; Type: DST P310; Gross weight: 0.143 Kilogram.
Overview
Part number 076G1023 from Danfoss, listed in Pressure Sensors & Transmitters. Specifications on file: - common Pin 2; + output Pin 3; + supply Pin 1; Accuracy, max. +/- FS [%] 1 %. KKM Solutions quotes this part with pricing and availability confirmed per order.
This listing covers the Danfoss 076G1023, a part number in the DST P310 category. The manufacturer's published data for this part number specifies Electrical connection: Round Packard Metri-Pack and Type: DST P310.
Key manufacturer data on file for this item includes Gross weight: 0.143 Kilogram; Net weight: 0.121 Kilogram; Volume: 0.253 Liter; EAN: 5715162440360; Product group: Sensors; Product Name Description: Pressure transmitter; China RoHS compliance: Out of scope; Contains batteries: No; EU RoHS compliance: Yes with exemptions; Packing format: Multi pack; Quantity per packing format: 20 pc; REACH Candidate List substances: Lead (CAS no. 7439-92-1). The complete technical table is shown in the Specifications tab on this page.
Specifications
| - common | Pin 2 |
|---|---|
| + output | Pin 3 |
| + supply | Pin 1 |
| Accuracy, max. +/- FS [%] | 1 % |
| Accuracy, typical +/- FS [%] | 0.5 % |
| Adj. zero point and span | No |
| Ambient temperature range [°C] [max] | 125 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [Max] | 257 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | C UL US UL RecognizedCE |
| Approval standard | E227388E31024 |
| Autofrettage Pressure | 500 bar |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Compensated temp. range [°C] [Max] | 125 °C |
| Compensated temp. range [°C] [Min] | -40 °C |
| Compensated temp. range [°F] [Max] | 257 °F |
| Compensated temp. range [°F] [Min] | -40 °F |
| Contains batteries | No |
| EAN | 5715162440360 |
| Electrical conn. Male/Female | Male |
| Electrical connection | Round Packard Metri-Pack |
| Electrical connection size | 3 pin |
| Electrical connection standard | 150.2 SERIES |
| Enclosure rating IP | IP65 |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Fault signal level | 2 |
| Flush diaphragm | No |
| Gross weight | 0.143 Kilogram |
| High Clipping Level | 99 |
| Identical product | 076G4008 |
| International Article Number | 5715162440360 |
| Intrinsically safe | No |
| Low Clipping Level | 4 |
| Medium temperature range [°C] [Max] | 125 °C |
| Medium temperature range [°C] [Min] | -40 °C |
| Medium temperature range [°F] [Max] | 257 °F |
| Medium temperature range [°F] [Min] | -40 °F |
| Net weight | 0.121 Kilogram |
| Output signal | Ratio metric |
| Overload pressure max. [bar] | 960 bar |
| Packing format | Multi pack |
| Pressure connection HEX [mm] | 27 mm |
| Pressure connection size | 1/4-18 |
| Pressure connection standard | ANSI/ASME B1.20.1 |
| Pressure connection type | NPT |
| Pressure Male/Female | Male |
| Pressure range [bar] [Max] | 159 bar |
| Pressure range [bar] [Min] | -1 bar |
| Pressure range [psi] [Max] | 2306 psi |
| Pressure range [psi] [Min] | -14.5 psi |
| Pressure unit reference | Sealed gauge |
| Product group | Sensors |
| Product Name Description | Pressure transmitter |
| Pulse-snubber | Yes |
| Quantity per packing format | 20 pc |
| Ratiometric of Vsupply [%] [Max] | 90 % |
| Ratiometric of Vsupply [%] [Min] | 10 % |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Response time max. [ms] | 4 ms |
| SCIP dossier no. | cad3914f-8db1-488c-b0ad-3a20ac1ebb41 |
| SCIP dossier product name | DST P300 |
| Specification key | DST P310-9736-C2AC04-0 |
| Supply voltage [V] DC [max] | 5.5 V |
| Supply voltage [V] DC [min] | 4.5 V |
| Type | DST P310 |
| UL evaluated | Yes |
| Volume | 0.253 Liter |
Product details
| Manufacturer | Danfoss |
|---|---|
| Manufacturer part number | 076G1023 |
| Product category | Pressure Sensors & Transmitters |
| Published specifications | 70 attributes listed |
| Related part numbers | 7 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for 076G1023?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 076G1023?
076G1023 is made by Danfoss and is listed in our Pressure Sensors & Transmitters category. KKM Solutions is an independent distributor, not an authorized Danfoss dealer: we source the exact Danfoss part number 076G1023, and the quote confirms condition and lead time before you order.
Is the 076G1023 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the 076G1023, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of 076G1023?
No published lifecycle status is on file for 076G1023. Danfoss lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of 076G1023?
Key specifications include - common: Pin 2; + output: Pin 3; + supply: Pin 1; Accuracy, max. +/- FS [%]: 1 %. The full specification table on this page lists every published attribute for this part.
What voltage does 076G1023 use?
Per the published specification for 076G1023: Supply voltage [V] DC [max]: 5.5 V; Supply voltage [V] DC [min]: 4.5 V. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What is the IP rating of 076G1023?
Per the published specification for 076G1023: Enclosure rating IP: IP65. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What thread or connection does 076G1023 use?
Per the published specification for 076G1023: Pressure connection size: 1/4-18; Pressure connection type: NPT. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can 076G1023 ship?
Lead time for 076G1023 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
