Beckhoff EL6695 — EtherCAT Terminals
The EL6695 EtherCAT bridge terminal enables real-time data exchange between EtherCAT Terminal strands with different masters. Asynchronous communication via AoE, FoE, EoE, NPI, etc. is also supported. Synchronization of distributed clocks is possible in
| Approvals/markings | CE, UL |
|---|---|
| Bit width in the process image | max. 3 kbyte per direction (dependent on the EtherCAT master, TwinCAT currently max. 1400 byte) |
| Cable length | 100 m 100BASE-TX, secondary port |
| Current consumption | primary: E-bus 400 mA; secondary: 70 mA/24 V |
| Distributed clocks | yes |
| Electrical isolation | 500 V (E-bus/secondary side) |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Function | EtherCAT distributed clock synchronization, data exchange |
| Hardware diagnostics | status LEDs |
| Number Of Ports | 2 x EtherCAT input/output |
| Operating Temperature | 0…55°C |
| Power Supply | primary: via the E-bus, secondary: via connector, 24 V |
| Protect. rating/installation pos. | IP20/variable |
| Relative Humidity | 95%, no condensation |
| Special Features | usable in TwinCAT as a reference clock, synchronous data exchange, flexible PDO mapping, supports AoE, EoE, FoE, VoE |
| Storage Temperature | -25…+85°C |
| Technology | primary side: E-bus (terminal strand), secondary side: 2 x 100 Mbit/s Ethernet, RJ45, In/Out |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| Weight | approx. 75 g |
Frequently Asked Questions
How do I get pricing for EL6695?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the EL6695?
EL6695 is a Beckhoff part. KKM Solutions sources Beckhoff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of EL6695?
Key specifications include Approvals/markings: CE, UL; Bit width in the process image: max. 3 kbyte per direction (dependent on the EtherCAT master, TwinCAT currently max. 1400 byte); Cable length: 100 m 100BASE-TX, secondary port; Current consumption: primary: E-bus 400 mA; secondary: 70 mA/24 V. The full specification table on this page lists every published attribute for this part.
How quickly can EL6695 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
