EL6601 Beckhoff EtherCAT Terminal, 1-port communication interface, Ethernet switch port
KKM Solutions is an independent parts distributor, not an authorized Beckhoff dealer — how we source.
Beckhoff EL6601 - EtherCAT Terminals - Weight: approx. 75 g; Operating Temperature: -25…+60°C; Storage Temperature: -40…+85°C.
Overview
Part number EL6601 from Beckhoff, listed in Fieldbus Modules & Gateways. Specifications on file: Approvals/markings CE, CCC, UL, ATEX, IECEx, cFMus; Cable length up to 100 m twisted pair; Configuration no; Current consumption E-bus typ. 260 mA. KKM Solutions quotes this part with pricing and availability confirmed per order.
The Beckhoff EL6601 is part of the EtherCAT Terminals range in our industrial catalog. The manufacturer's published data for this part number specifies Weight: approx. 75 g and Operating Temperature: -25…+60°C.
ATEX:
II 3 G Ex ec IIC T4 Gc
IECEx:
Ex ec IIC T4 Gc
cFMus:
Class I, Division 2, Groups A, B, C, D
Class I, Zone 2, AEx ec IIC T4 Gc
Key manufacturer data on file for this item includes Storage Temperature: -40…+85°C; Relative Humidity: 95%, no condensation; Cable length: up to 100 m twisted pair; Protocol: all Ethernet (IEEE 802.3)-based protocols, store and forward switching mode; Special Features: support of RT Ethernet, publisher/subscriber, DHCP/BootP server; Number Of Ports: 1; Power Supply: via the E-bus; Approvals/markings: CE, CCC, UL, ATEX, IECEx, cFMus; Vibration/shock resistance: conforms to EN 60068-2-6/EN 60068-2-27; EMC immunity/emission: conforms to EN 61000-6-2/EN 61000-6-4; Electrical isolation: 500 V (E-bus/Ethernet); Protect. rating/installation pos.: IP20/variable. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Approvals/markings | CE, CCC, UL, ATEX, IECEx, cFMus |
|---|---|
| Bus system | all Ethernet (IEEE 802.3)-based protocols, store and forward switching mode |
| Cable length | up to 100 m twisted pair |
| Configuration | no |
| Current consumption E-bus | typ. 260 mA |
| Current consumption power contacts | – |
| Data transfer rates | 10/100 Mbit/s, IEEE 802.3u auto-negotiation, half or full duplex at 10 and 100 Mbit/s possible, automatic settings |
| Distributed clocks | – |
| Electrical isolation | 500 V (E-bus/Ethernet) |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Ethernet interface | 10BASE-T/100BASE-TX Ethernet with 1 x RJ45 |
| Ex marking | ATEX: II 3 G Ex ec IIC T4 Gc IECEx: Ex ec IIC T4 Gc cFMus: Class I, Division 2, Groups A, B, C, D Class I, Zone 2, AEx ec IIC T4 Gc |
| Hardware diagnostics | status LEDs |
| Number Of Ports | 1 |
| Operating Temperature | -25…+60°C |
| Power Supply | via the E-bus |
| Protect. rating/installation pos. | IP20/variable |
| Protocol | all Ethernet (IEEE 802.3)-based protocols, store and forward switching mode |
| Relative Humidity | 95%, no condensation |
| Special Features | support of RT Ethernet, publisher/subscriber, DHCP/BootP server |
| Storage Temperature | -40…+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| Weight | approx. 75 g |
Product details
| Manufacturer | Beckhoff |
|---|---|
| Manufacturer part number | EL6601 |
| Product category | Fieldbus Modules & Gateways |
| Published specifications | 23 attributes listed |
| Related part numbers | 15 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for EL6601?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the EL6601?
EL6601 is made by Beckhoff and is listed in our Fieldbus Modules & Gateways category. KKM Solutions is an independent distributor, not an authorized Beckhoff dealer: we source the exact Beckhoff part number EL6601, and the quote confirms condition and lead time before you order.
Is the EL6601 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the EL6601, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of EL6601?
No published lifecycle status is on file for EL6601. Beckhoff lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of EL6601?
Key specifications include Approvals/markings: CE, CCC, UL, ATEX, IECEx, cFMus; Bus system: all Ethernet (IEEE 802.3)-based protocols, store and forward switching mode; Cable length: up to 100 m twisted pair; Configuration: no. The full specification table on this page lists every published attribute for this part.
What operating temperature is EL6601 rated for?
Per the published specification for EL6601: Operating Temperature: -25…+60°C. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How much does EL6601 weigh?
Per the published specification for EL6601: Weight: approx. 75 g. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can EL6601 ship?
Lead time for EL6601 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
