WEG 30018ST3HIE449T-W22 — Motor
Weg Electric 30018ST3HIE449T-W22, 300 Hp, 447/9T Frame, 1800 RPM, 575 Vac, TEFC, 3 PH, Foot-mounted, W22 IEEE 841 NEMA Premium Efficiency.
Overview
30018ST3HIE449T-W22, 300 Hp, 447/9T Frame, 1800 RPM, 575 Vac, TEFC, 3 PH, Foot-mounted, W22 IEEE 841 NEMA Premium Efficiency. Engineering Data The W22 IEEE 841 motors were especially designed to operate in petrochemical and chemical industries. The motor has cast iron frame, flexible mounting, solid and whole feet, low noise levels, anticorrosive internal coating and high efficiency. Product features Standard NEMA MG-1 Frequency 60 Hz Voltage 575 V Number of poles 4 Degree of Protection IP55 Synchronous speed 1800 rpm Output rating 300 HP Mounting Foot-mounted Flange Without Mounting F-1 Terminal box¹ Left position Enclosure IC411 - TEFC Frame 447/9T Output 300 HP (220 kW) Number of Poles 4 Frequency 60 Hz Rated speed 1780 rpm Slip 1.11 % Rated voltage 575 V Rated current 264 A L. R. Amperes 1716 A LRC 6.5x(Code G) No load current 76.0 A Rated torque 885 ft.lb Locked rotor torque 229 % Breakdown torque 229 % Locked rotor time 28s (cold) 16s (hot) Moment of inertia (J) 89.6 sq.ft.lb Design B Insulation Class F Service factor 1.15 Temperature rise 80 K Duty Cycle Cont.(S1) Starting Method Direct On Line Ambient temperature -20°C to +40°C Altitude 1000 m.a.s.l. Degree of Protection IP55 Enclosure IC411 - TEFC Mounting F-1 Rotation¹ Both (CW and CCW) Noise level² 75.0 dB(A)
Specifications
| Tag | WEG Electric |
|---|---|
| Weight | 2966.0 lb |
Product details
| Manufacturer | WEG |
|---|---|
| Manufacturer part number | 30018ST3HIE449T-W22 |
| KKM catalog reference | WEG-30018ST3HIE449T-W22 |
| Product category | Motor |
| Published specifications | 2 attributes listed |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does 30018ST3HIE449T-W22 cost?
30018ST3HIE449T-W22 is listed at CA$48,231.36 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the 30018ST3HIE449T-W22?
30018ST3HIE449T-W22 is a WEG part. KKM Solutions sources WEG components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is 30018ST3HIE449T-W22 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for 30018ST3HIE449T-W22 — check WEG's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 30018ST3HIE449T-W22?
Key specifications include Tag: WEG Electric; Weight: 2966.0 lb. The full specification table on this page lists every published attribute for this part.
How quickly can 30018ST3HIE449T-W22 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
