WEG 30018ET3X5009-W50MV — Motor

30018ET3X5009-W50MV, 300 Hp, 1800 Rpm, 5009/10 Frame, 2300/4160 Vac, TEFC, 3 PH, Foot-mounted. Engineering Data WEG W50 motors offer not only excellent performance, but comply with the strictest efficiency and safety criteria in the most severe applications. The compact design provides high performance, while their robust frames ensure low vibration levels. The new mechanical concept not only optimizes characteristics like mass and length, but also offers product versatility and reduced maintenance. Note: This item can be derated to 50HP less than the rated power. Please contact Inside Sales for more information. Product features Standard NEMA MG-1 Frequency 60 Hz Voltage 2300/4160 V Number of poles 4 Degree of Protection IP55 Synchronous speed 1800 rpm Output rating 300 HP Mounting Foot-mounted Flange Without Mounting F-1 Terminal box¹ Left position Enclosure IC411 - TEFC Frame 5009/10 Output 300 HP (220 kW) Number of Poles 4 Frequency 60 Hz Rated speed 1782 rpm Slip 1.00 % Rated voltage 2300 V Rated current 68.4 A L. R. Amperes 424 A LRC 6.2x(Code G) No load current 22.0 A Rated torque 884 ft.lb Locked rotor torque 140 % Breakdown torque 210 % Locked rotor time 36s (cold) 20s (hot) Design A Insulation Class F Service factor 1.00 Temperature rise 80 K Duty Cycle Cont.(S1) Starting Method Direct On Line Ambient temperature -20°C to +40°C Altitude 1000 m.a.s.l. Degree of Protection IP55 Enclosure IC411 - TEFC Mounting F-1 Rotation¹ Both (CW and CCW) Noise level² 79.0 dB(A)
