WEG 20012ET3GKD505Z-W22 — Motor
Weg Electric 20012ET3GKD505Z-W22, 200 Hp, 504/5TZ Frame, 1200 RPM, 460 Vac, TEFC, 3 PH, Foot-mounted, W22 NEMA Premium Efficiency.
Overview
20012ET3GKD505Z-W22, 200 Hp, 504/5TZ Frame, 1200 RPM, 460 Vac, TEFC, 3 PH, Foot-mounted, W22 NEMA Premium Efficiency. Engineering Data Designed to meet the demanding requirements of the rock crushing industry, the Crusher Duty motor comes standard with 4140 high strength shafts and heavy duty roller bearings. This motor complies or exceeds EISA 2016 requlations. Compliment your WEG Crusher Duty motor with our TPH2 Starter to complete your solution! Product features Standard NEMA MG-1 Frequency 60 Hz Voltage 460 V Number of poles 6 Degree of Protection IP55 Synchronous speed 1200 rpm Output rating 200 HP Mounting Foot-mounted Flange Without Mounting F-1 Terminal box¹ Left position Enclosure IC411 - TEFC Frame 504/5TZ Output 200 HP (150 kW) Number of Poles 6 Frequency 60 Hz Rated speed 1191 rpm Slip 0.75 % Rated voltage 460 V Rated current 243 A L. R. Amperes 1701 A LRC 7.0x(Code H) No load current 101 A Rated torque 882 ft.lb Locked rotor torque 220 % Breakdown torque 260 % Locked rotor time 36s (cold) 20s (hot) Design A Insulation Class F Temperature rise 80 K Duty Cycle Cont.(S1) Starting Method Direct On Line Ambient temperature -20°C to +40°C Altitude 1000 m.a.s.l. Degree of Protection IP55 Enclosure IC411 - TEFC Mounting F-1 Rotation¹ Both (CW and CCW) Noise level² 70.0 dB(A)
Specifications
| Tag | WEG Electric |
|---|---|
| Weight | 2459.0 lb |
Product details
| Manufacturer | WEG |
|---|---|
| Manufacturer part number | 20012ET3GKD505Z-W22 |
| KKM catalog reference | WEG-20012ET3GKD505Z-W22 |
| Product category | Motor |
| Published specifications | 2 attributes listed |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does 20012ET3GKD505Z-W22 cost?
20012ET3GKD505Z-W22 is listed at CA$32,931.23 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the 20012ET3GKD505Z-W22?
20012ET3GKD505Z-W22 is a WEG part. KKM Solutions sources WEG components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is 20012ET3GKD505Z-W22 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for 20012ET3GKD505Z-W22 — check WEG's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 20012ET3GKD505Z-W22?
Key specifications include Tag: WEG Electric; Weight: 2459.0 lb. The full specification table on this page lists every published attribute for this part.
How quickly can 20012ET3GKD505Z-W22 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
