US Motors ASB2982T 1.65 HP 2-Pole ODP 1-Phase 3450 RPM Electric Motor
| Ambient | 50 |
|---|---|
| Breakdown Torque | 81.61 |
| Breakdown Torque Uom | OZFT |
| Frme | 56 |
| Full Load Amps Primary | 7.4/1.4 |
| Hertz | 60 |
| Horsepower | 1.65 HP |
| Horsepower 2 | 0.26 |
| Insulation Class | B |
| Kva Code Letter | H |
| Locked Rotor Amps | 29.98 |
| Locked Rotor Torque Uom | OZFT |
| Locked-Rotor Torque | 7.184 |
| Motor Enclosure | ODP |
| Motor Type | FHP |
| Mounting | SQUARE FLANGE |
| Number Speeds | 2 |
| Opposite End Bearing | 6203 |
| Phasetype | 1_PERMANENT SPLIT CA |
| Poles | 2 |
| Poles 2 | 4 |
| Rotation | CW LEAD END |
| Rpm 2 | 1725 |
| Runcapmfd | 20 |
| Runcapvolts | 370 |
| Shaft Code | Y |
| Shaft End Bearing | 6203 |
| Shipping Weight | 31 |
| Speed | 3450 RPM |
| Stack | 2.375 |
| Stator Diameter | 6.3 |
| Thermal protection | AUTOMATIC RESET |
| Volts | 230 |
| Volts Primary | 230 V |
Frequently Asked Questions
How do I get pricing for ASB2982T?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the ASB2982T?
ASB2982T is a US Motors part. KKM Solutions sources US Motors components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of ASB2982T?
Key specifications include Ambient: 50; Breakdown Torque: 81.61; Breakdown Torque Uom: OZFT; Frme: 56. The full specification table on this page lists every published attribute for this part.
How quickly can ASB2982T ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
