Schunk PGF 50-IS
| Closing time [s] | 0.07 |
|---|---|
| Closing/opening time with spring [s] | 0.5 |
| Cylinder volume per double stroke [cm³] | 14.0 |
| Height Z [mm] | 55.0 |
| IP protection class | 40 |
| Length X [mm] | 76.0 |
| Max Operating Pressure (bar) | 6.5 |
| Max. ambient temperature [°C] | 90.0 |
| Max. axial force Fz max. [N] | 400.0 |
| Max. permissible finger length [mm] | 50.0 |
| Max. permissible weight per finger [kg] | 0.25 |
| Min. ambient temperature [°C] | 5.0 |
| Min. operating pressure [bar] | 4.0 |
| Min. spring force [N] | 100.0 |
| Moment Mx max. [Nm] | 10.0 |
| Moment My max. [Nm] | 25.0 |
| Moment Mz max. [Nm] | 25.0 |
| Nominal operating pressure [bar] | 6.0 |
| Opening force (with finger lengths of 0 mm) [N] | 375.0 |
| Opening force [N] | 360.0 |
| Opening time [s] | 0.03 |
| Recommended workpiece weight [kg] | 1.2 |
| Repeat accuracy [mm] | 0.02 |
| Stroke per jaw [mm] | 7.5 |
| Weight (Kg) | 0.35 |
| Width Y [mm] | 38.0 |
Frequently Asked Questions
How do I get pricing for 340362?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 340362?
340362 is a Schunk part. KKM Solutions sources Schunk components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 340362?
Key specifications include Closing time [s]: 0.07; Closing/opening time with spring [s]: 0.5; Cylinder volume per double stroke [cm³]: 14.0; Height Z [mm]: 55.0. The full specification table on this page lists every published attribute for this part.
How quickly can 340362 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
