Schunk PRH 050-100-PB-54
Schunk 306875 - Rotary Actuators - Interface: PROFIBUS, USB (parameterization); Number of digital inputs: 4.0; Number of digital outputs: 0.0.
This listing covers the Schunk 306875, a part number in the Rotary Actuators category. The manufacturer's published data for this part number specifies Interface: PROFIBUS, USB (parameterization) and Number of digital inputs: 4.0.
The specification set recorded for this part number covers Number of digital outputs: 0.0; Weight (Kg): 0.75; Repeat accuracy: 0.004; IP protection class: 54; Min. ambient temperature [°C]: 0.0; Max. ambient temperature [°C]: 40.0; Length X [mm]: 117.5; Width Y [mm]: 67.0; Height Z [mm]: 64.0; Moment My max. [Nm]: 15.0; Nominal torque [Nm]: 2.0; Nominal voltage [V]: 24.0. The complete technical table is shown in the Specifications tab on this page.
| Axial run-out [mm] | 0.01 |
|---|---|
| Control electronics | integrated |
| Encoder system | Encoder (incremental) |
| Force Fx max. [N] | 200.0 |
| Force Fz max. [N] | 200.0 |
| Height Z [mm] | 64.0 |
| Interface | PROFIBUS, USB (parameterization) |
| IP protection class | 54 |
| Length X [mm] | 117.5 |
| Max. ambient temperature [°C] | 40.0 |
| Max. current [A] | 2.4 |
| Max. permissible mass moment of inertia [kgm²] | 0.057 |
| Max. rotational speed [1/min] | 60.0 |
| Min. ambient temperature [°C] | 0.0 |
| Moment My max. [Nm] | 15.0 |
| Nominal current [A] | 1.3 |
| Nominal speed [1/min] | 35.0 |
| Nominal torque [Nm] | 2.0 |
| Nominal voltage [V] | 24.0 |
| Number of digital inputs | 4.0 |
| Number of digital outputs | 0.0 |
| Peak torque [Nm] | 4.8 |
| Power supply [V] | 24.0 |
| PROFIBUS interface [Mbit/s] | 12.0 |
| Repeat accuracy | 0.004 |
| Run-out accuracy [mm] | 0.01 |
| Transmission | 100:1 |
| USB interface | Device |
| Weight (Kg) | 0.75 |
| Width Y [mm] | 67.0 |
Frequently Asked Questions
How do I get pricing for 306875?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 306875?
306875 is a Schunk part. KKM Solutions sources Schunk components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 306875?
Key specifications include Axial run-out [mm]: 0.01; Control electronics: integrated; Encoder system: Encoder (incremental); Force Fx max. [N]: 200.0. The full specification table on this page lists every published attribute for this part.
How quickly can 306875 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
