Schunk PZV 100
Schunk 304002 - Centric Grippers - Weight (Kg): 1.6; Diameter D [mm]: 112.0; Max Operating Pressure (bar): 8.0.
This listing covers the Schunk 304002, a part number in the Centric Grippers category. The manufacturer's published data for this part number specifies Weight (Kg): 1.6 and Diameter D [mm]: 112.0.
Key manufacturer data on file for this item includes Max Operating Pressure (bar): 8.0; Stroke per jaw [mm]: 8.0; Closing force [N]: 1800.0; Closing force (with finger lengths of 0 mm) [N]: 2056.0; Recommended workpiece weight [kg]: 9.0; Cylinder volume per double stroke [cm³]: 120.0; Min. operating pressure [bar]: 2.0; Nominal operating pressure [bar]: 6.0; Min. air purge pressure [bar]: 0.5; Max. air purge pressure [bar]: 1.0; Closing time [s]: 0.04; Opening time [s]: 0.04. The complete technical table is shown in the Specifications tab on this page.
| Closing force (with finger lengths of 0 mm) [N] | 2056.0 |
|---|---|
| Closing force [N] | 1800.0 |
| Closing time [s] | 0.04 |
| Cylinder volume per double stroke [cm³] | 120.0 |
| Diameter D [mm] | 112.0 |
| Height Z [mm] | 55.0 |
| IP protection class | 40 |
| Max Operating Pressure (bar) | 8.0 |
| Max. air purge pressure [bar] | 1.0 |
| Max. ambient temperature [°C] | 90.0 |
| Max. axial force Fz max. [N] | 1500.0 |
| Max. permissible finger length [mm] | 80.0 |
| Max. permissible weight per finger [kg] | 0.6 |
| Min. air purge pressure [bar] | 0.5 |
| Min. ambient temperature [°C] | 5.0 |
| Min. operating pressure [bar] | 2.0 |
| Moment Mx max. [Nm] | 60.0 |
| Moment My max. [Nm] | 95.0 |
| Moment Mz max. [Nm] | 55.0 |
| Nominal operating pressure [bar] | 6.0 |
| Opening force (with finger lengths of 0 mm) [N] | 2201.0 |
| Opening force [N] | 1900.0 |
| Opening time [s] | 0.04 |
| Recommended workpiece weight [kg] | 9.0 |
| Repeat accuracy [mm] | 0.01 |
| Stroke per jaw [mm] | 8.0 |
| Weight (Kg) | 1.6 |
