Omron G2RV-ST700-AP AC100 Switching relay
Omron G2RV-ST700-AP AC100 switching relay with 100 VAC coil, SPDT contacts, LED and mechanical indicator, and screw terminals.
The Omron G2RV-ST700-AP AC100 is a switching relay designed for low-power control applications. It features an SPDT contact arrangement with LED and mechanical indicators for clear status visualization.
This relay operates with a 100 VAC coil voltage and handles a maximum switching voltage of 30 VAC or 36 VDC at up to 50 mA. Its rated resistive load is 50 mA at 30 VAC and 50 mA at 36 VDC, with power consumption of approximately 0.8 VA. It uses screw terminals and operates within a temperature range of –40 to +55°C. The unit is RoHS compliant.
| Coil voltage | 100 VAC |
|---|---|
| Contact arrangement | SPDT |
| Indicator | LED & Mechanical |
| Max. switching current | 50 mA |
| Max. switching voltage | 30 VAC, 36 VDC |
| Operating Temperature | –40 to +55°C |
| Power consumption | Approx. 0.8 VA |
| Rated load (resistive) | 50 mA @ 30 VAC, 50 mA @ 36 VDC |
| RoHS Compliant | Yes |
| Terminal | Screw Terminals |
Frequently Asked Questions
How do I get pricing for G2RV-ST700-AP AC100?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the G2RV-ST700-AP AC100?
G2RV-ST700-AP AC100 is a Omron part. KKM Solutions sources Omron components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of G2RV-ST700-AP AC100?
Key specifications include Coil voltage: 100 VAC; Contact arrangement: SPDT; Indicator: LED & Mechanical; Max. switching current: 50 mA. The full specification table on this page lists every published attribute for this part.
How quickly can G2RV-ST700-AP AC100 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
