Omron G2RV-ST700 AC/DC24
Omron G2RV-ST700 AC/DC24 SPDT electromechanical relay with 24 VAC/DC coil, screw terminals, LED and mechanical indicators, and RoHS compliance.
The Omron G2RV-ST700 AC/DC24 is an electromechanical relay designed for reliable switching in industrial applications. It features both LED and mechanical indicators for clear status visualization and screw terminals for secure wiring.
This relay operates on 24 VAC/DC with a power consumption of approximately 0.5 VA and 300 mW DC. It supports a SPDT contact arrangement and handles resistive loads up to 6 A at 250 VAC or 30 VDC, with maximum switching voltages of 440 VAC and 125 VDC. The relay is RoHS compliant and operates within a temperature range of –40 to +55°C, with maximum switching power ratings of 1,500 VA and 180 W for resistive loads, and 500 VA and 60 W for inductive loads.
| Coil voltage | 24 VAC/DC |
|---|---|
| Contact arrangement | SPDT |
| Indicator | LED & Mechanical |
| Max. switching current | 6A |
| Max. switching power (inductive) | 500 VA, 60 W |
| Max. switching power(resistive) | 1,500 VA, 180 W |
| Max. switching voltage | 440 VAC, 125 VDC |
| Operating Temperature | –40 to +55°C |
| Power consumption | Approx. 0.5 VA, Approx. 300 mW DC |
| Rated load (resistive) | 6 A @ 250 VAC, 6 A @ 30 VDC |
| RoHS Compliant | Yes |
| Terminal | Screw Terminals |
Frequently Asked Questions
How do I get pricing for G2RV-ST700 AC/DC24?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the G2RV-ST700 AC/DC24?
G2RV-ST700 AC/DC24 is a Omron part. KKM Solutions sources Omron components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of G2RV-ST700 AC/DC24?
Key specifications include Coil voltage: 24 VAC/DC; Contact arrangement: SPDT; Indicator: LED & Mechanical; Max. switching current: 6A. The full specification table on this page lists every published attribute for this part.
How quickly can G2RV-ST700 AC/DC24 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
