Kimray EZP
Kimray EZP - Cage Guided - Weight: 263 lbs; Connection type: 150 RF; Body material: Steel.
In our catalog, the EZP from Kimray is listed under the Cage Guided category. The manufacturer's published data for this part number specifies Weight: 263 lbs and Connection type: 150 RF.
Published specifications for this part include Body material: Steel; Operation: Pneumatic; Connection Size: 3 "; Body style: Through Body; Catalog Page: 01:20.1; Max Working Pressure: 285 psig; NACE MR0175: Option Available for NACE MR0175 compliance or certification; Trim Size: 2 "; Trim Type: Equal Percentage; Leakage Class: Class VI; Process Fluid: Liquid and Gas; Face-to-Face Length: 11.75 ". The complete technical table is shown in the Specifications tab on this page.
| Actuator Crack Open Pressure | 6 psig |
|---|---|
| Actuator Full Open Pressure | 30 psig |
| Actuator Spring Nominal Pressure | 30 psig |
| Body material | Steel |
| Body style | Through Body |
| Catalog Page | 01:20.1 |
| Cf | 0.75 |
| Connection Size | 3 " |
| Connection type | 150 RF |
| Face-to-Face Length | 11.75 " |
| Fail Position | Closed - Field Reversible |
| Leakage Class | Class VI |
| Max Cv | 52.6 |
| Max Supply Gas Pressure | 45 psig |
| Max Working Pressure | 285 psig |
| NACE MR0175 | Option Available for NACE MR0175 compliance or certification |
| Operation | Pneumatic |
| Process Fluid | Liquid and Gas |
| Trim Size | 2 " |
| Trim Type | Equal Percentage |
| Weight | 263 lbs |
