SF5300 IFM Flow sensor for connection to an evaluation unit
KKM Solutions is an independent parts distributor, not an authorized IFM dealer — how we source.
IFM SF5300 - Flow sensor for connection to an evaluation unit - Application: high temperature; Product type: Flow sensor for connection to an evaluation unit.
Overview
Part number SF5300 from IFM, listed in Flow Sensors & Meters. Specifications on file: Application high temperature; Connection to control monitor VS3000; Greatest sensitivity 3...60; Housing tubular. KKM Solutions quotes this part with pricing and availability confirmed per order.
This listing covers the IFM SF5300, a part number in the Flow sensor for connection to an evaluation unit category. The manufacturer's published data for this part number specifies Application: high temperature.
knurled nut: stainless steel; Cable gland: FKM; nut for cable gland: brass nickel-plated; Sleeve: brass nickel-plated
Key manufacturer data on file for this item includes Product type: Flow sensor for connection to an evaluation unit; Cable: 6 m, silicone; Maximum cable length: 100 m; 5 x 0.34 mm²; Response time: 1...10; Process Connection: threaded connection M18 x 1,5 Internal thread; Medium temperature: 0...120; Housing: tubular; Media: Liquids; Gases; Protection: IP 67; Probe length (L): 45; Connection to control monitor: VS3000; Greatest sensitivity: 3...60; Installation length EL: 44. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Application | high temperature |
|---|---|
| Cable | 6 m, silicone; Maximum cable length: 100 m; 5 x 0.34 mm² |
| Connection to control monitor | VS3000 |
| Greatest sensitivity | 3...60 |
| Housing | tubular |
| Installation length EL | 44 |
| Key Features | Reliable monitoring of liquids and gases in pipes; For connection to an evaluation unit; Suitable for medium temperatures up to 120 °C; Simple process connection via adapter; Robust design for use in harsh industrial environments |
| Material | knurled nut: stainless steel; Cable gland: FKM; nut for cable gland: brass nickel-plated; Sleeve: brass nickel-plated |
| Materials (wetted parts) | stainless steel (1.4404 / 316L); O-ring: FKM 80 Shore A |
| Max. temperature gradient of medium | 300 |
| Media | Liquids; Gases |
| Medium temperature | 0...120 |
| MTTF | 8096 |
| Pack quantity | 1 pcs. |
| Probe diameter | 8.2 |
| Probe length (L) | 45 |
| Process Connection | threaded connection M18 x 1,5 Internal thread |
| Product type | Flow sensor for connection to an evaluation unit |
| Protection | IP 67 |
| Response time | 1...10 |
| Setting range | 3...300 |
| Specification Summary | Flow sensor for connection to evaluation units; Setting range (Liquids / Gases) 3...300 cm/s / 200...3000 cm/s; Medium temperature (Liquids / Gases) 0...120 °C / 0...100 °C; Pressure rating 300 bar; M18 x 1,5 Internal thread; cable |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | SF5300 |
| Product category | Flow Sensors & Meters |
| Published specifications | 22 attributes listed |
| Related part numbers | 1 other part number in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for SF5300?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the SF5300?
SF5300 is made by IFM and is listed in our Flow Sensors & Meters category. KKM Solutions is an independent distributor, not an authorized IFM dealer: we source the exact IFM part number SF5300, and the quote confirms condition and lead time before you order.
Is the SF5300 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the SF5300, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of SF5300?
No published lifecycle status is on file for SF5300. IFM lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of SF5300?
Key specifications include Application: high temperature; Cable: 6 m, silicone; Maximum cable length: 100 m; 5 x 0.34 mm²; Connection to control monitor: VS3000; Greatest sensitivity: 3...60. The full specification table on this page lists every published attribute for this part.
What material is SF5300 made of?
Per the published specification for SF5300: Material: knurled nut: stainless steel; Cable gland: FKM; nut for cable gland: brass nickel-plated; Sleeve: brass nickel-plated. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can SF5300 ship?
Lead time for SF5300 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
