SF5200 IFM Flow sensor for connection to an evaluation unit
KKM Solutions is an independent parts distributor, not an authorized IFM dealer — how we source.
IFM SF5200 - Flow sensor for connection to an evaluation unit - Material: stainless steel (1.4404 / 316L); Connector: 1 x M12; coding: A; Maximum cable length: 100 m.
Overview
Part number SF5200 from IFM, listed in Flow Sensors & Meters. Specifications on file: Application high temperature; Connection to control monitor VS3000; Dimensions M18 x 1.5 / L = 82; Greatest sensitivity 3...60. KKM Solutions quotes this part with pricing and availability confirmed per order.
In our catalog, the SF5200 from IFM is listed under the Flow sensor for connection to an evaluation unit category. The manufacturer's published data for this part number specifies Material: stainless steel (1.4404 / 316L).
Reliable monitoring of liquids and gases in pipes; For connection to an evaluation unit; Simple process connection via adapter; Very high pressure resistance; M12 connector for fast and easy connection
The specification set recorded for this part number covers Connector: 1 x M12; coding: A; Maximum cable length: 100 m; Dimensions: M18 x 1.5 / L = 82; Application: high temperature; Product type: Flow sensor for connection to an evaluation unit; Response time: 1...10; Process Connection: threaded connection M18 x 1,5 Internal thread; Medium temperature: -25...80; Housing: tubular; Media: Liquids; Gases; Protection: IP 67; Connection to control monitor: VS3000; Greatest sensitivity: 3...60. See the Specifications tab on this page for the full technical table.
Specifications
| Application | high temperature |
|---|---|
| Connection to control monitor | VS3000 |
| Connector | 1 x M12; coding: A; Maximum cable length: 100 m |
| Dimensions | M18 x 1.5 / L = 82 |
| Greatest sensitivity | 3...60 |
| Housing | tubular |
| Installation length EL | 44 |
| Key Features | Reliable monitoring of liquids and gases in pipes; For connection to an evaluation unit; Simple process connection via adapter; Very high pressure resistance; M12 connector for fast and easy connection |
| Material | stainless steel (1.4404 / 316L) |
| Materials (wetted parts) | stainless steel (1.4404 / 316L); O-ring: FKM 80 Shore A |
| Max. temperature gradient of medium | 300 |
| Media | Liquids; Gases |
| Medium temperature | -25...80 |
| MTTF | 8213 |
| Pack quantity | 1 pcs. |
| Probe diameter | 8.2 |
| Process Connection | threaded connection M18 x 1,5 Internal thread |
| Product type | Flow sensor for connection to an evaluation unit |
| Protection | IP 67 |
| Response time | 1...10 |
| Setting range | 3...300 |
| Specification Summary | Flow sensor for connection to evaluation units; Setting range (Liquids / Gases) 3...300 cm/s / 200...3000 cm/s; Medium temperature -25...80 °C; Pressure rating 300 bar; M18 x 1,5 Internal thread; Connector |
| Thread designation | M18 x 1.5 |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | SF5200 |
| Product category | Flow Sensors & Meters |
| Published specifications | 23 attributes listed |
| Related part numbers | 1 other part number in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for SF5200?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the SF5200?
SF5200 is made by IFM and is listed in our Flow Sensors & Meters category. KKM Solutions is an independent distributor, not an authorized IFM dealer: we source the exact IFM part number SF5200, and the quote confirms condition and lead time before you order.
Is the SF5200 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the SF5200, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of SF5200?
No published lifecycle status is on file for SF5200. IFM lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of SF5200?
Key specifications include Application: high temperature; Connection to control monitor: VS3000; Connector: 1 x M12; coding: A; Maximum cable length: 100 m; Dimensions: M18 x 1.5 / L = 82. The full specification table on this page lists every published attribute for this part.
What thread or connection does SF5200 use?
Per the published specification for SF5200: Thread designation: M18 x 1.5. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What material is SF5200 made of?
Per the published specification for SF5200: Material: stainless steel (1.4404 / 316L). Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can SF5200 ship?
Lead time for SF5200 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
