Inductive sensor - IQ2007
IFM IQ2007 - Inductive sensor - Weight: 42.7; Ambient temperature: -40...85; Connector: 1 x M12; coding: A; Contacts: 3.
The IFM IQ2007 is part of the Inductive sensor range in our industrial catalog. The manufacturer's published data for this part number specifies Weight: 42.7 and Ambient temperature: -40...85.
diecast zinc special coating; sensing face: PBT orange; LED window: TPU (urethane); potting: PUR
The specification set recorded for this part number covers Connector: 1 x M12; coding: A; Contacts: 3; Protection class: III; Dimensions: 20 x 8 x 32; Application: Industrial applications; Product type: Inductive sensor; Mounting: flush mountable; Cable: 0.3 m, PUR, Ø 4.9 mm; 3 x 0.34 mm²; Operating voltage: 10...30 DC; Current consumption: < 10; Reverse polarity protection: yes; Sensing range: 8; Overload protection: yes. See the Specifications tab on this page for the full technical table.
| Ambient temperature | -40...85 |
|---|---|
| Application | Industrial applications |
| Cable | 0.3 m, PUR, Ø 4.9 mm; 3 x 0.34 mm² |
| Connector | 1 x M12; coding: A; Contacts: 3 |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Current consumption | < 10 |
| Dimensions | 20 x 8 x 32 |
| Electrical design | NPN |
| Housing | rectangular |
| Hysteresis | 1...15 |
| Increased sensing range | yes |
| Key Features | Flush mounting and high temperature range improves sensor life and robustness; Particularly compact housing for use where space is restricted |
| Material | diecast zinc special coating; sensing face: PBT orange; LED window: TPU (urethane); potting: PUR |
| Max. voltage drop switching output DC | 2.5 |
| Mounting | flush mountable |
| MTTF | 1607 |
| Operating distance | 0...6.48 |
| Operating voltage | 10...30 DC |
| Output function | normally open |
| Overload protection | yes |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output DC | 100 |
| Product type | Inductive sensor |
| Protection | IP 65; IP 66; IP 67; IP 68 |
| Protection class | III |
| Real sensing range Sr | 8 ± 10 % |
| Reverse polarity protection | yes |
| Sensing range | 8 |
| Short circuit protection | yes |
| Special Feature | Increased sensing range |
| Specification Summary | Inductive sensor; 20 x 8 x 32 mm; Sensing range 8 mm flush mountable; normally open; DC; NPN; 0.3 m PUR-Cable; M12 Connector; IP 65; IP 66; IP 67; IP 68; Ambient temperature -40...85 °C; Switching frequency 400 Hz |
| Switch-point drift | -10...10 |
| Switching frequency DC | 400 |
| Weight | 42.7 |
