IN0131 IFM Inductive sensor
KKM Solutions is an independent parts distributor, not an authorized IFM dealer — how we source.
IFM IN0131 - Inductive sensor - Material: housing: PA; Ambient temperature: -25...70.
Overview
Part number IN0131 from IFM, listed in Inductive Proximity Sensors. Specifications on file: Ambient temperature -25...70; Dimensions 33 x 60 x 92; Frequency AC 47...63; Housing rectangular. KKM Solutions quotes this part with pricing and availability confirmed per order.
IFM IN0131 is an Inductive sensor catalog item from IFM. The manufacturer's published data for this part number specifies Material: housing: PA.
For monitoring valve positions; For reliable position feedback on valve actuators; High shock and vibration resistance; Quick and secure mounting with only three screws
Key manufacturer data on file for this item includes Ambient temperature: -25...70; Protection class: II; Dimensions: 33 x 60 x 92; Application: Position sensor for valve actuators; actuator control; Product type: Inductive sensor; Mounting: non-flush mountable; Operating voltage: 20...250 AC/DC; Current consumption: < 15; Reverse polarity protection: yes; Sensing range: 4; Overload protection: no; Output function: 2 x normally open. See the Specifications tab on this page for the full technical table.
Specifications
| Ambient temperature | -25...70 |
|---|---|
| Application | Position sensor for valve actuators; actuator control |
| Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
| Dimensions | 33 x 60 x 92 |
| Frequency AC | 47...63 |
| Housing | rectangular |
| Hysteresis | 1...15 |
| Key Features | For monitoring valve positions; For reliable position feedback on valve actuators; High shock and vibration resistance; Quick and secure mounting with only three screws |
| Material | housing: PA |
| Max. leakage current | 2.5 (250 V AC) / 1.3 (110 V AC) / 0.8 (24 V DC) |
| Max. voltage drop switching output AC | 6.5 |
| Max. voltage drop switching output DC | 6 |
| Minimum load current | 5 |
| Mounting | non-flush mountable |
| MTTF | 307 |
| Operating distance | 0...3.25 |
| Operating voltage | 20...250 AC/DC |
| Output function | 2 x normally open |
| Overload protection | no |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output AC | 250; (350 (...50 °C)) |
| Permanent current rating of switching output DC | 100 |
| Product type | Inductive sensor |
| Protection | IP 67 |
| Protection class | II |
| Real sensing range Sr | 4 ± 10 % |
| Required protection | miniature fuse to IEC60127-2 sheet 1; ≤ 2 A; fast acting |
| Reverse polarity protection | yes |
| Sensing range | 4 |
| Short circuit protection | no |
| Short-time current rating of switching output | 2200; (20 ms / 0,5 Hz) |
| Specification Summary | Inductive sensor; 33 x 60 x 92 mm; Sensing range 4 mm non-flush mountable; 2 x normally open; AC/DC; Terminal strip in the terminal chamber; IP 67; 3-wire; Ambient temperature -25...70 °C; Switching frequency 25 Hz AC / 50 Hz DC |
| Switch-point drift | -10...10 |
| Switching frequency AC | 25 |
| Switching frequency DC | 50 |
Product details
| Manufacturer | IFM |
|---|---|
| Manufacturer part number | IN0131 |
| Product category | Inductive Proximity Sensors |
| Published specifications | 35 attributes listed |
| Related part numbers | 5 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for IN0131?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the IN0131?
IN0131 is made by IFM and is listed in our Inductive Proximity Sensors category. KKM Solutions is an independent distributor, not an authorized IFM dealer: we source the exact IFM part number IN0131, and the quote confirms condition and lead time before you order.
Is the IN0131 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the IN0131, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of IN0131?
No published lifecycle status is on file for IN0131. IFM lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of IN0131?
Key specifications include Ambient temperature: -25...70; Application: Position sensor for valve actuators; actuator control; Correction factor: steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3; Dimensions: 33 x 60 x 92. The full specification table on this page lists every published attribute for this part.
What voltage does IN0131 use?
Per the published specification for IN0131: Max. voltage drop switching output AC: 6.5; Max. voltage drop switching output DC: 6. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What is the current rating of IN0131?
Per the published specification for IN0131: Permanent current rating of switching output AC: 250; (350 (...50 °C)); Permanent current rating of switching output DC: 100. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
What material is IN0131 made of?
Per the published specification for IN0131: Material: housing: PA. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can IN0131 ship?
Lead time for IN0131 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
