Inductive sensor - IIP200
IFM IIP200 - Inductive sensor - Weight: 124.3; Ambient temperature: -25...70; Connector: 1 x M12; coding: A; Contacts: 3.
IFM IIP200 is a Inductive sensor catalog item from IFM. The manufacturer's published data for this part number specifies Weight: 124.3 and Ambient temperature: -25...70.
housing: stainless steel (1.4404 / 316L); sensing face: LCP white; LED window: PEI; lock nuts: stainless steel (1.4404 / 316L)
The specification set recorded for this part number covers Connector: 1 x M12; coding: A; Contacts: 3; Tightening torque: 7; Protection class: III; Dimensions: M30 x 1.5 / L = 60; Product type: Inductive sensor; Mounting: flush mountable; Communication interface: IO-Link; Operating voltage: 10...30 DC; Current consumption: < 20; Reverse polarity protection: yes; Resolution: 15; Repeatability: < 40 µm. See the Specifications tab on this page for the full technical table.
| Ambient temperature | -25...70 |
|---|---|
| Application | Non-contact detection of the smallest distance changes in the micrometer range; Industrial applications |
| Communication interface | IO-Link |
| Connector | 1 x M12; coding: A; Contacts: 3 |
| Current consumption | < 20 |
| Dimensions | M30 x 1.5 / L = 60 |
| Electrical design | PNP/NPN; (configurable) |
| Embedded software included | yes |
| Housing | Threaded type |
| IO-Link revision | 1.1 |
| Key Features | For a precise position monitoring on machines; Wide operating temperature range; Very high repeatability; Non-contact detection of the smallest distance changes in the micrometer range |
| Linearity deviation | ± 40 µm |
| Magnetic field immune | yes |
| Material | housing: stainless steel (1.4404 / 316L); sensing face: LCP white; LED window: PEI; lock nuts: stainless steel (1.4404 / 316L) |
| Max. electromagnetic field immunity | 300 |
| Max. voltage drop switching output DC | 2.5 |
| Measuring range IO-Link | 1...10 |
| Min. process cycle time | 3.2 |
| Mounting | flush mountable |
| MTTF | 1341 |
| Operating voltage | 10...30 DC |
| Output function | normally open / closed; (configurable) |
| Overload protection | yes |
| Pack quantity | 1 pcs. |
| Permanent current rating of switching output DC | 100 |
| Product type | Inductive sensor |
| Protection | IP 65; IP 66; IP 67; IP 68; IP 69K |
| Protection class | III |
| Repeatability | < 40 µm |
| Required master port class | A |
| Resolution | 15 |
| Reverse polarity protection | yes |
| SDCI standard | IEC 61131-9 CDV |
| Short circuit protection | yes |
| SIO mode | yes |
| Special Feature | Magnetic-field immune |
| Specification Summary | Inductive sensor; M30 x 1.5 / L = 60 mm; normally open / closed; (configurable); DC; PNP/NPN; M12 Connector; IP 65; IP 66; IP 67; IP 68; IP 69K; 3-wire; Ambient temperature -25...70 °C; Switching frequency 75 Hz |
| Switch point IO-Link | 2...9.7 |
| Switching frequency DC | 75 |
| Temperature drift | ± 4 µm/K |
| Thread designation | M30 x 1.5 |
| Tightening torque | 7 |
| Transmission type | COM2 (38,4 kBaud) |
| Weight | 124.3 |
