IO-Link master with EtherNet/IP interface - AL1920
IFM AL1920 - IO-Link master with EtherNet/IP interface - Material: housing: PA orange; Weight: 319.2; Storage Temperature: -25...85.
In our catalog, the AL1920 from IFM is listed under the IO-Link master with EtherNet/IP interface category. The manufacturer's published data for this part number specifies Material: housing: PA orange and Weight: 319.2.
Separation between automation network and IT network; Reliable transmission of machine data, process parameters and diagnostic data to the controller; With EtherNet/IP interface and separate MQTT JSON interface; Space saving small design for control panel mounting
Key manufacturer data on file for this item includes Storage Temperature: -25...85; Type of mounting: Mounting on DIN rail; (TH35 (EN 60715)); Ambient temperature: -25...65; Protocol: EtherNet/IP; Protection class: III; Dimensions: 125.7 x 50 x 105.3; Number of digital inputs: 8; (IO-Link Port Class A); Number of digital outputs: 8; (IO-Link Port Class A); Application: I/O modules for use in the control cabinet; Product type: IO-Link master with EtherNet/IP interface; Short-circuit-proof: yes; Communication interface: Ethernet; IO-Link. The complete technical table is shown in the Specifications tab on this page.
| Ambient temperature | -25...65 |
|---|---|
| Application | I/O modules for use in the control cabinet |
| Communication interface | Ethernet; IO-Link |
| Current consumption | 300...3900; (US) |
| Design | housing for DIN rail mounting |
| Digital inputs protected against short circuits | yes |
| Dimensions | 125.7 x 50 x 105.3 |
| Housing | rectangular |
| IO-Link revision | 1.1 |
| Key Features | Separation between automation network and IT network; Reliable transmission of machine data, process parameters and diagnostic data to the controller; With EtherNet/IP interface and separate MQTT JSON interface; Space saving small design for control panel mounting |
| Material | housing: PA orange |
| Max. current load per output | 300 |
| Max. current load total | 3.6 |
| Max. relative air humidity | 90 |
| MTTF | 78 |
| Number of digital inputs | 8; (IO-Link Port Class A) |
| Number of digital outputs | 8; (IO-Link Port Class A) |
| Number of inputs and outputs | Number of digital inputs: 8; Number of digital outputs: 8 |
| Number of ports class A | 8 |
| Operating voltage | 20...30 DC; (US ; to SELV/PELV) |
| Pack quantity | 1 pcs. |
| Product type | IO-Link master with EtherNet/IP interface |
| Protection | IP 20 |
| Protection class | III |
| Protocol | EtherNet/IP |
| Short-circuit-proof | yes |
| Specification Summary | IO-Link master CabinetLine; 125.7 x 50 x 105.3 mm; Number of digital inputs 8; Number of digital outputs 8; IP 20 |
| Storage Temperature | -25...85 |
| Switching level high | 11...30 |
| Switching level low | 0...5 |
| Total number of inputs and outputs | 16; (configurable) |
| Transmission rate | 10 MBit/s; 100 MBit/s |
| Transmission standard | 10Base-T; 100Base-TX |
| Transmission type | COM1 (4,8 kBaud); COM2 (38,4 kBaud); COM3 (230,4 kBaud) |
| Type of mounting | Mounting on DIN rail; (TH35 (EN 60715)) |
| Weight | 319.2 |
Frequently Asked Questions
How do I get pricing for AL1920?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the AL1920?
AL1920 is a IFM part. KKM Solutions sources IFM components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of AL1920?
Key specifications include Ambient temperature: -25...65; Application: I/O modules for use in the control cabinet; Communication interface: Ethernet; IO-Link; Current consumption: 300...3900; (US). The full specification table on this page lists every published attribute for this part.
How quickly can AL1920 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
