Danfoss Pressure transmitter, DST P070, -1 bar - 14 bar, -14.5 psi - 203 psi
| - common | Pin A |
|---|---|
| + output | Pin C |
| + supply | Pin B |
| Ambient temperature range [°C] [max] | 85 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Approval | CEC UL US UL Recognized |
| CE evaluated | Yes |
| China RoHS compliance | Out of scope |
| Compensated temp. range [°C] [Max] | 125 °C |
| Compensated temp. range [°C] [Min] | -40 °C |
| Contains batteries | No |
| EAN | 5715255153788 |
| Electrical connection | Round Packard Metri-Pack |
| Electrical connection size | 3 pin |
| Electrical connection standard | 150.2 SERIES |
| Electrical Connector Colour | Green |
| Enclosure rating IP | IP67 |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 7(a)7(c)-I |
| Gross weight | 0.025 Kilogram |
| Housing material | 304L |
| Identical product | NONE |
| In scope of WEEE | No |
| International Article Number | 5715255153788 |
| Medium temperature range [°C] [Max] | 135 °C |
| Medium temperature range [°C] [Min] | -40 °C |
| Net weight | 0.02 Kilogram |
| Output signal | Ratio metric |
| Overload pressure max. [bar] | 42 bar |
| Packing format | Industrial pack |
| Pressure connection size | Solder tube |
| Pressure connection standard | For solder tube |
| Pressure connection type | Solder, ODM |
| Pressure Male/Female | Male |
| Pressure range [bar] [Max] | 14 bar |
| Pressure range [bar] [Min] | -1 bar |
| Pressure range [psi] [Max] | 203 psi |
| Pressure range [psi] [Min] | -14.5 psi |
| Pressure unit reference | Sealed gauge |
| Product group | Sensors |
| Product Name Description | Pressure transmitter |
| Pulse-snubber | No |
| Quantity per packing format | 64 pc |
| Ratiometric of Vsupply [%] [Max] | 90 % |
| Ratiometric of Vsupply [%] [Min] | 10 % |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Response time max. [ms] | 2 ms |
| SCIP dossier no. | 8dfe6f25-e974-4313-ac51-cfbcd9bdb573 |
| SCIP dossier product name | DST P070 |
| Specification key | DST P070 RATIO-1-14BAR SG I/64 |
| Supply voltage [V] DC | 5 V |
| TEB inside CTR ±FS [%] | 2 % |
| Type | DST P070 |
| UL evaluated | Yes |
| Wetted part material | 304L/other |
