BSP00R8 (BSP B400-DV004-D05S1A-S4) - Pressure transmitter - Measuring range: 0...400 bar, Accuracy: ±0.5 % FSO BFSL, Overload pressure: 1200 bar, Burst pressure: 1500.00 bar, Operating voltage Ub: 18...30 VDC, Interface: IO-Link 1.1, Switching output: NPN NO/NC, Connection: Connector, M12x1-Male, 4-pin, Process connection: G 1/4" (DIN 3852), Process connection material: 1.4571 stainless steel, Gasket, material: without, welded, Housing material: Stainless steel (1.4301), Media temperature: -40...125 °C, Ambient temperature: -25...85 °C, IP rating: IP67, Approval/Conformity: CE, cULus, WEEE - BALLUFF USA
| Accuracy | ±0.5 % FSO BFSL |
|---|---|
| Ambient temperature | -25...85 °C |
| Approval/Conformity | CE, cULus, WEEE |
| Burst Pressure | 1500.00 bar |
| Connection | Connector, M12x1-Male, 4-pin |
| Gasket Material | without, welded |
| Housing material | Stainless steel (1.4301) |
| Interface | IO-Link 1.1 |
| IP Rating | IP67 |
| Measuring range | 0...400 bar |
| Media temperature | -40...125 °C |
| Operating voltage Ub | 18...30 VDC |
| Overload pressure | 1200 bar |
| Process Connection | G 1/4" (DIN 3852) |
| Process connection material | 1.4571 stainless steel |
| Switching output | NPN NO/NC |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for BSP00R8?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the BSP00R8?
BSP00R8 is a Balluff part. KKM Solutions sources Balluff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is BSP00R8 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for BSP00R8 — check Balluff's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of BSP00R8?
Key specifications include Accuracy: ±0.5 % FSO BFSL; Ambient temperature: -25...85 °C; Approval/Conformity: CE, cULus, WEEE; Burst Pressure: 1500.00 bar. The full specification table on this page lists every published attribute for this part.
How quickly can BSP00R8 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
