Balluff BIS M-113-03/L
BIS018Y (BIS M-113-03/L) - HF data carriers (13.56 MHz) - List price USA: 14.88 USD - Product Group: HF (13.56 MHz), Dimension: Ø 4.2 x 3.5 mm, Antenna type: round, UID serial number, read-only: 8 Byte, Memory type: EEPROM, Supported data carrier types: DIN ISO 15693, User data, read/write: 112 Byte, Storage temperature: -40...85 °C, Ambient temperature: -40...85 °C, Housing material: Epoxy-resin/fiberglass, PVC, IP rating: IPx8, Installation: metal-free (clear zone), on metal, flush in metal, Approval/Conformity: CE, WEEE - BALLUFF USA
| Ambient temperature | -40...85 °C |
|---|---|
| Antenna type | round |
| Approval/Conformity | CE, WEEE |
| Dimension | Ø 4.2 x 3.5 mm |
| Housing material | Epoxy-resin/fiberglass, PVC |
| Installation | metal-free (clear zone), on metal, flush in metal |
| IP Rating | IPx8 |
| Memory type | EEPROM |
| Product group | HF (13.56 MHz) |
| Storage Temperature | -40...85 °C |
| Supported data carrier types | DIN ISO 15693 |
| UID serial number, read-only | 8 Byte |
| User data, read/write | 112 Byte |
Frequently Asked Questions
How do I get pricing for BIS018Y?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the BIS018Y?
BIS018Y is a Balluff part. KKM Solutions sources Balluff components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of BIS018Y?
Key specifications include Ambient temperature: -40...85 °C; Antenna type: round; Approval/Conformity: CE, WEEE; Dimension: Ø 4.2 x 3.5 mm. The full specification table on this page lists every published attribute for this part.
How quickly can BIS018Y ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
