Allen-Bradley Motor Protection Circuit-Breaker 140M-C2E-C32

Pricing Quote only

Email [email protected] or call (825) 454-5367 for pricing and availability.

Request a Quote

Order desk replies within 1 business day. No obligation.
Quoting several parts? Build one list, get one quote.
Worldwide shipping — site, warehouse or freight forwarder.

Lifecycle: Discontinued Reported by the manufacturer, not a live availability check. Sourcing discontinued and obsolete parts is core to what we do — we locate remaining new-old-stock through our supplier network, and identify a form-fit-function equivalent where a part is genuinely unavailable. Try the obsolete part lookup.

Allen-Bradley Motor Protection Circuit-Breaker 140M-C2E-C32

Name: Allen-Bradley Motor Protection Circuit-Breaker 140M-C2E-C32
Brand: Allen-Bradley
SKU: 140M-C2E-C32

Brand: Allen-Bradley SKU: 140M-C2E-C32

Ships Same Day* Worldwide Shipping

Allen-Bradley 140M-C2E-C32 - Manual Motor Protectors - Width: 45 mm mm; Height: 90 mm mm; Weight: 317 lb.

Sourced to exact specCross-checked against manufacturer part data

Fast quote turnaroundOur order desk replies within 1 business day

Worldwide shippingWe ship to your site, warehouse, or freight forwarder

Allen-Bradley 140M-C2E-C32 is a Manual Motor Protectors catalog item from Allen-Bradley. The manufacturer's published data for this part number specifies Width: 45 mm mm and Height: 90 mm mm.

Fixed setting 13...14 x Ie max. Ie max. = maximum values of setting ranges, (±20 %)

The specification set recorded for this part number covers Weight: 317 lb; Lifecycle Status: Discontinued; Degree of protection (IP): IP2X; Depth: 74.5 mm; Overload release current setting: 27 A; Type of electrical connection of main circuit: Screw connection; Device construction: Built-in device fixed built-in technique; Electrical life cycle: (Ie max.) 100000 ops; Mechanical life operations: 100000 /h; Number of poles: 3; Switching frequency, max: 25 ops/h; Type of control element: Turn button. The complete technical table is shown in the Specifications tab on this page.

Ambient operating temperature	-25 °C
Ambient storage temperature	-40 °C
Ambient temperature compensation	-20 °C
Amperage Rating	27 - 32 A,MxRtg MCPs(no OvPrt)is 1200.0A
Auxiliary circuits/overvoltage category-inv	6kV/III @ rated impulse withstand voltage (Uimp)
Back up fuse (gG, gL) current rating (if Icc ≥ Icu ) per IEC	80A @ 690V
Breaking capacity	Standard breaking capacity
Contactor size (Type 2 coordination), min-inv	100-C37 @ 600V
Contactor size, min-inv	100-C37, UL 508-manual motor controller (100-C)
Current Range	27...32 A
Degree of protection (IP)	IP2X
Dependence on temperature	No current reduction @ 60 °C-inv
Depth	74.5 mm
Device construction	Built-in device fixed built-in technique
Dry heat	100 °C, relative humidity < 50 %, 7 d (60086-2-2)-inv
Electrical life cycle	(Ie max.) 100000 ops
Factory option	No circuit-breaker auxiliary or trip contacts
Frame Size	Frame size C, 32 A
Fuse or circuit breaker per NEC, max	450 A, UL 508-manual motor controller
Fuse or circuit breaker rating per NEC, max	450 A, UL 508-manual motor controller with 100-C contactor
Height	90 mm mm
Hp rating, max	7.5Hp @ 200V, 3-phase
KW rating, max	25 kW @ 690V (AC-3), 3-phase
Lifecycle Status	Discontinued
Magnetic release current	Fixed setting 13...14 x Ie max. Ie max. = maximum values of setting ranges, (±20 %)
Magnetic release current per IEC	448 A
Magnetic trip current	448 A
Main circuits/overvoltage category	6kV/III @ rated impulse withstand voltage (Uimp)
Mechanical life operations	100000 /h
Moisture change climate	23 °C/83 % relative humidity and 40 °C/92 % relative humidity, 56 cycles (600068-2-30)-inv
Moisture heat	40 °C, relative humidity 93 %, 56 d (60068-2-3)-inv
Number of poles	3
Overload release current setting	27 A
Phase failure sensitive	true
Phase loss protection	Differential release
Pollution degree	3
Protection type	Adjustable thermal/fixed magnetic (13 x In)
Rated frequency	50/60 Hz
Rated operating voltage	32 A
Rated operating voltage, max	690V per IEC, SEV, VDE0660
Rated operation power at AC-3, 230 V	7.5 kw
Rated operation power at AC-3, 400 V	15 kw
Rated operational current (Ie) per IEC	32 A
Rated service short circuit breaking capacity (Ics) per IEC	6kA @ 500V
Rated short-circuit breaking capacity lcu at 400 V, AC	15 kA
Rated supply current	0.1 A
Rated thermal current	0.1...32A @ 60°C ambient temperature (Ith)-inv
Shock resistance	Transport (60068-2-27): 30 G, 11 ms, all axes
Short circuit current (Type 2 coordination), max-inv	5kA @ 600V
Short circuit current for group motor installation with 100-C contactor, max-inv	5kA @ 600V, UL 508-manual motor controller
Short circuit current for group motor installation, max	5kA @ 600V, UL 508-manual motor controller
Short circuit current for motor disconnect with 100-C contactor, max-inv	5kA @ 600V, UL 508-manual motor controller
Short circuit current for motor disconnect, max	10kA @ 480V, UL 508-manual motor controller
Site altitude	To 2000 N.N.(m)
Switch off technique	Thermomagnetic
Switching frequency, max	25 ops/h
Switching of standard motors per IEC	7.5 kW @ 230/240V, 3-phase
Terminal Type	Screw connection
Total power loss (Pv) for circuit breaker at rated load operating temperature-inv	6 W
Trip Class	10
Type of control element	Turn button
Type of electrical connection of main circuit	Screw connection
Ultimate short circuit breaking capacity (Icu) per IEC	6kA @ 500V
Vibration resistance	ops (60068-2-6): 5 G
Weight	317 lb
Width	45 mm mm
With integrated auxiliary switch	false
With integrated under voltage release	false
With thermal protection	true

Request a quote for this part

Email [email protected] or call (825) 454-5367 for pricing and availability.

Name Email Company Phone Ship to (helps us quote freight) Quantity

Message Urgent — line down. Prioritise this and call me back.

Quotes back within 1 business day — usually the same day. Need it faster? Call (825) 454-5367, answered 24/7.

Frequently Asked Questions

How do I get pricing for 140M-C2E-C32?

KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.

Who manufactures the 140M-C2E-C32?

140M-C2E-C32 is a Allen-Bradley part. KKM Solutions sources Allen-Bradley components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.

Is 140M-C2E-C32 discontinued, and can I still get one?

Yes — our product data lists 140M-C2E-C32 with a manufacturer lifecycle status of "Discontinued". You can still get one: sourcing discontinued, superseded and long-obsolete parts is core to what KKM Solutions does. We locate remaining new-old-stock through our supplier network, and where a part is genuinely unavailable we identify a form-fit-function equivalent and confirm the differences with you before you commit. Send 140M-C2E-C32 through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.

What are the key specifications of 140M-C2E-C32?

Key specifications include Ambient operating temperature: -25 °C; Ambient storage temperature: -40 °C; Ambient temperature compensation: -20 °C; Amperage Rating: 27 - 32 A,MxRtg MCPs(no OvPrt)is 1200.0A. The full specification table on this page lists every published attribute for this part.

How quickly can 140M-C2E-C32 ship?

In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
