Weidmuller WDK 10 L
Weidmuller 1415510000 - Feed-through and PE terminal Blocks - Width: 9.9 mm mm; Height: 85 mm mm; Storage Temperature: -25 °C...55 °C.
The Weidmuller 1415510000 is part of the Feed-through and PE terminal Blocks range in our industrial catalog. The manufacturer's published data for this part number specifies Width: 9.9 mm mm and Height: 85 mm mm.
Multi-tier modular terminal, Screw connection, dark beige, 10 mm², 800 V, Number of connections: 2, Number of levels: 1, TS 35, V-0
The specification set recorded for this part number covers Storage Temperature: -25 °C...55 °C; Nominal current: 57 A; Type of mounting: Snap-on; Ambient temperature: -50 °C…75 °C; Type: WDK 10 L; Depth: 69 mm; Net weight: 23.802 g; Colour: dark beige; Rated voltage: 800 V; Stripping length: 12 mm; Blade Size: 1.0 x 5.5 mm; ROHS: Conform. See the Specifications tab on this page for the full technical table.
| Ambient temperature | -50 °C…75 °C |
|---|---|
| Basic material | Wemid |
| Blade Size | 1.0 x 5.5 mm |
| Certificate No. (CSA) | 200039-1057876 |
| Certificate No. (UR) | E60693 |
| Clamping range, max. | 16 mm² |
| Clamping range, min. | 1.5 mm² |
| Clamping screw | M 4 |
| Colour | dark beige |
| Conductor size Factory wiring max. (UR) | 6 AWG |
| Conductor size Factory wiring min. (UR) | 18 AWG |
| Conductor size Field wiring max. (UR) | 6 AWG |
| Conductor size Field wiring min. (UR) | 18 AWG |
| Connection cross-section, finely stranded, min. | 1.5 mm² |
| Connection cross-section, stranded, max. | 16 mm² |
| Connection cross-section, stranded, min. | 1.5 mm² |
| Connection direction | on side |
| Connection type, additional connection | Screw connection |
| Continuous operating temp., max. | 120 °C |
| Continuous operating temp., min. | -50 °C |
| Current at maximum wires | 70 A |
| Current size C (CSA) | 70 A |
| Delivery status | This article will no longer be available in the future. |
| Depth | 69 mm |
| Depth (inches) | 2.717 inch |
| Depth including DIN rail | 69.5 mm |
| ECLASS 14.0 | 27-25-01-02 |
| ECLASS 15.0 | 27-25-01-02 |
| End cover plate required | Yes |
| ETIM 10.0 | EC000897 |
| ETIM 8.0 | EC000897 |
| ETIM 9.0 | EC000897 |
| Explosion-tested version | No |
| Gauge to IEC 60947-1 | B6 |
| GTIN (EAN) | 4050118216509 |
| Height | 85 mm mm |
| Height (inches) | 3.346 inch |
| Levels cross-connected internally | No |
| Mounting rail | TS 35 |
| N-function | No |
| Net weight | 23.802 g |
| Nominal current | 57 A |
| Number of clamping points per level | 2 |
| Number of connections | 2 |
| Number of levels | 1 |
| Number of potentials | 1 |
| Number of potentials per tier | 1 |
| Open sides | right |
| Order No. | 1415510000 |
| PE connection | No |
| PE function | No |
| PEN function | No |
| Pollution severity | 3 |
| Power loss in accordance with IEC 60947-7-x | 1.82 W |
| Qty. | 50 items |
| Rated cross-section | 10 mm² |
| Rated DC voltage | 800 V |
| Rated impulse withstand voltage | 8 kV |
| Rated voltage | 800 V |
| REACH SVHC | No SVHC above 0.1 wt% |
| ROHS | Conform |
| RoHS Compliance Status | Compliant without exemption |
| Standards | IEC 60947-7-1 |
| Storage Temperature | -25 °C...55 °C |
| Stripping length | 12 mm |
| Surge voltage category | III |
| Tightening torque (max) | 1.9 Nm Nm |
| Tightening torque, min. | 1.2 Nm |
| Twin wire-end ferrules, max. | 6 mm² |
| Twin wire-end ferrules, min. | 1.5 mm² |
| Type | WDK 10 L |
| Type of connection | Screw connection |
| Type of connection 2 | Screw connection |
| Type of mounting | Snap-on |
| UL 94 flammability rating | V-0 |
| Version | Multi-tier modular terminal, Screw connection, dark beige, 10 mm², 800 V, Number of connections: 2, Number of levels: 1, TS 35, V-0 |
| Voltage size C (CSA) | 1000 V |
| Volume resistance according to IEC 60947-7-x | 0.56 mΩ |
| Width | 9.9 mm mm |
| Width (inches) | 0.39 inch |
| Wire connection cross section AWG, max. | AWG 6 |
| Wire connection cross section AWG, min. | AWG 16 |
| Wire connection cross section, finely stranded, max. | 16 mm² |
| Wire connection cross section, finely stranded, min. | 1.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, max. | 16 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, min. | 1.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max. | 16 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min. | 1.5 mm² |
| Wire connection cross-section, solid core, max. | 16 mm² |
| Wire connection cross-section, solid core, min. | 1.5 mm² |
| Wire cross section max. (CSA) | 6 AWG |
| Wire cross section min. (CSA) | 18 AWG |
