WEG SSW060170T2257ESZ WEG Soft Starter (170 Amps, Three Phase, 220-575V)

WEG SSW060170T2257ESZ, SSW06 Soft Starter Type,170 Amps, Three Phase, 220-575V, 3 Frame Size, IP00 Protected Chassis Enclosure , WEG Soft Starter Applications The SSW06 is WEGs third generation Soft Starter line. The keypad, with dual display, has red LED digits which provide visibility and make programming easier. Integral bypass contacts eliminate heat dissipation once the motor is at full voltage, which makes it extremely compact and allows for simple integration into non ventilated enclosures and replacement of electromechanical starters in Motor Control Centers. Features IP00 protected chassis enclosure Six isolated 24Vdc programmable digital inputs One 0 - 10Vdc programmable analooutput One 4 - 20mA programmable analooutput Motor PTC thermistor input RS-232 serial interface Adjustable acceleration and deceleration ramps (1 - 299 seconds) Adjustable pedestal voltage (25 - 90% of line voltage) Diagnostic features: Motor overload, over current and phase loss, motor immediate over and under current, SCR over temperature and fault, line phase loss and phase sequence, line over and under voltage Display readings: Motor current, voltage, kW and power factor, line voltage and frequency, four last fault trips, run and power-up timers Tech Specs Brand WEG Model Number SSW060170T2257ESZ Type SSW06 Soft Starter HP @ 230V 60 HP @ 460V 125 HP @ 575V 150 Soft Starter AMPS 170 Power Supply 220-575V Phase Three Phase Frame Size 3 Dimensions (in.) H x W x D 17.3 x 8.8 x 11 Enclosure IP00 Protected Chassis Enclosure Weight (lbs.) 41 Notes See Drive Literature Support Documents (pdf) SSW06 Drive Literature
