WEG 5 HP 3 Phase Magnetic Starter NEMA 4X 208-240V 11 - 17 Amp PESW-B18V24EX-R66

WEG PESW-18V24EX-R32 5 HP Three Phase Magnetic Starter NEMA 4X Enclosure Brand new WEG PESW-18V24EX-R32 5 horsepower, three phase, 208-240 volt magnetic starter with a NEMA 4X enclosure. This is a great quality starter with a built-in overload which is adjustable from 11-17 amps and is equipped with a manual reset button. The PESW magnetic starters are ideal to protect motors and ensure reliable operation year after year. Assembled together in a NEMA 4x enclosure with a RESET button on the cover for quick and easy operation. The NEMA 4X enclosure is constructed for either indoor or outdoor use to provide a degree of protection against falling dirt, rain, sleet, snow, windblown dust, splashing water, and hose-directed water. Will be undamaged by the external formation of ice on the enclosure. PROFESSIONAL INSTALLATION RECOMMENDED Specifications • HP at 208-240 Volts: 5 HP • Overload Range Min (Amps): 11 • Overload Range Max (Amps): 17 • Coil Voltage: 208-240 Volts • Phase: Three • Frequency: 60Hz • Enclosure Rating: NEMA 4X • Enclosure Material: Plastic • Push Button Function: Reset • Weight: 1.7 • Approximate Dimensions (W x H x D): 3-7/8" x 7-1/16" x 4-1/4" Standard Features • Fast acceleration and high initial torque • Bimetallic overload relays - class 10 • Adjustable trip current • Ambient temperature compensated for -4°F to 140°F • Phase-loss sensitivity protection • Selectable manual or automatic reset • Electrically isolated NO-NC auxiliary contacts • UL, IEC, and CSA Certified If you are using this starter on an air compressor, you will also need a pressure switch to control the starter. In this application the pressure switch controls the On and Off of the starter according to the pressure setting of the pressure switch.
