WEG PCQ115 — Pool and Spa Pump Motors
WEG PCQ115 WEG Pool and Spa Pump Motor (1.5 HP, L48Y FRAME, 115/230 V, SINGLE PHASE, ODP Enclosure, 3450 RPM)
Overview
WEG Motor PCQ115, 1.5 HP , 3450 RPM, L48Y FRAME, 115/230 V , SINGLE PHASE, 60 Hz , ODP , Spa Motor Applications Pool and Spa Features Spa Pump Motors, Single Phase, Rolled Steel, Standard Efficiency, ODP Tech Specs Brand WEG Motors Model Number PCQ115 HP 1.5 HP RPM 3450 FRAME L48Y VOLTAGE 115/230 V PHASE SINGLE FREQUENCY 60 Hz ENCLOSURE ODP APPROXIMATE WEIGHT (lb) 25 FEET NO TERMINAL BOX LEFT FLANGE FC-149 RATED CURRENT 17.7/8.85 A LOCKED ROTOR CURRENT IL IN 5.9 LOCKED ROTOR CURRENT 104/52.2 A LOCKED ROTOR TORQUE 1.3 BREAKDOWN TORQUE 2.1 EFFICIENCY 50 64.5 EFFICIENCY 75 69 EFFICIENCY 100 69.6 POWER FACTOR 50 0.61 POWER FACTOR 75 0.72 POWER FACTOR 100 0.79 SERVICE FACTOR 1.1 INERTIA KGM2 0.00152 kgm INERTIA SQ FT 0.03607 sq.ft. LOCKED ROTOR TIME 6 s NOISE LEVEL - ALTITUDE 1000 DUTY CYCLE S1 AMBIENT TEMPERATURE -20C - +50C DEGREE OF PROTECTION IP21 NO-LOAD CURRENT 10.5/5.25 A INSULATION CLASS B FULL LOAD TORQUE NM 3.05 Nm FULL LOAD TORQUE FT 2.25 .ft SLIP 0.0417 DESIGN - TEMPERATURE RISE 80 K BEARINGS D E 6203 2RS BEARINGS N D E 6203 ZZ REGREASING INTERVAL D E - REGREASING INTERVAL N D E - GREASE AMOUNT D E - GREASE AMOUNT N D E -
Specifications
| Tag | WEG Pump Motors |
|---|---|
| Weight | 25.0 lb |
Product details
| Manufacturer | WEG |
|---|---|
| Manufacturer part number | PCQ115 |
| KKM catalog reference | WEG-PCQ115 |
| Product category | Pool and Spa Pump Motors |
| Published specifications | 2 attributes listed |
| Related part numbers | 11 other part numbers in this family |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does PCQ115 cost?
PCQ115 is listed at CA$419.29 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the PCQ115?
PCQ115 is a WEG part. KKM Solutions sources WEG components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is PCQ115 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for PCQ115 — check WEG's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of PCQ115?
Key specifications include Tag: WEG Pump Motors; Weight: 25.0 lb. The full specification table on this page lists every published attribute for this part.
How quickly can PCQ115 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
