WEG 25036ET3X5009-W50MV — Motor

25036ET3X5009-W50MV, 250 Hp, 3600 Rpm, 5009/10 Frame, 2300/4160 Vac, TEFC, 3 PH, Foot-mounted. Engineering Data WEG W50 motors offer not only excellent performance, but comply with the strictest efficiency and safety criteria in the most severe applications. The compact design provides high performance, while their robust frames ensure low vibration levels. The new mechanical concept not only optimizes characteristics like mass and length, but also offers product versatility and reduced maintenance. Note: This item can be derated to 50HP less than the rated power. Please contact Inside Sales for more information. Product features Standard NEMA MG-1 Frequency 60 Hz Voltage 2300/4160 V Number of poles 2 Degree of Protection IP55 Synchronous speed 3600 rpm Output rating 250 HP Mounting Foot-mounted Flange Without Mounting F-1 Terminal box¹ Left position Enclosure IC411 - TEFC Frame 5009/10 Output 250 HP (185 kW) Number of Poles 2 Frequency 60 Hz Rated speed 3574 rpm Slip 0.72 % Rated voltage 2300 V Rated current 55.5 A L. R. Amperes 355 A LRC 6.4x(Code G) No load current 12.0 A Rated torque 50.8 kgfm Locked rotor torque 100 % Breakdown torque 210 % Locked rotor time 27s (cold) 15s (hot) Design A Insulation Class F Service factor 1.00 Temperature rise 80 K Duty Cycle Cont.(S1) Starting Method Direct On Line Ambient temperature -20°C to +40°C Altitude 1000 m.a.s.l. Degree of Protection IP55 Enclosure IC411 - TEFC Mounting F-1 Rotation¹ CW Noise level² 79.0 dB(A)
