WEG 10018OP3VFP404TS-W40 — Motor
Weg Electric 10018OP3VFP404TS-W40, 100 Hp, 404/5TS Frame, 1800 RPM, 200/400 Vac, ODP, 3 PH, Foot-mounted, W40 High Efficiency.
Overview
10018OP3VFP404TS-W40, 100 Hp, 404/5TS Frame, 1800 RPM, 200/400 Vac, ODP, 3 PH, Foot-mounted, W40 High Efficiency. Engineering Data W40 is a platform of Open Drip Proof motors (ODP) designed for industrial application in order to have a compact and light solution for the customer. Product features Standard NEMA MG-1 Frequency 60 Hz Voltage 200/400 V Number of poles 4 Degree of Protection IP23 Synchronous speed 1800 rpm Output rating 100 HP Mounting Foot-mounted Flange Without Mounting F-1 Terminal box¹ Left position Enclosure IC01 - ODP Frame 404/5TS Output 100 HP (75 kW) Number of Poles 4 Frequency 60 Hz Rated speed 1775 rpm Slip 1.39 % Rated voltage 200/400 V Rated current 267/133 A L. R. Amperes 1654/827 A LRC 6.2x(Code G) No load current 88.5/44.3 A Rated torque 296 ft.lb Locked rotor torque 220 % Breakdown torque 250 % Locked rotor time 25s (cold) 14s (hot) Moment of inertia (J) 17.5 sq.ft.lb Design B Insulation Class F Service factor 1.15 Temperature rise 80 K Duty Cycle Cont.(S1) Starting Method Direct On Line Ambient temperature -20°C to +40°C Altitude 1000 m.a.s.l. Degree of Protection IP23 Enclosure IC01 - ODP Mounting F-1 Rotation¹ Both (CW and CCW)
Specifications
| Tag | WEG Electric |
|---|---|
| Weight | 819.0 lb |
Product details
| Manufacturer | WEG |
|---|---|
| Manufacturer part number | 10018OP3VFP404TS-W40 |
| KKM catalog reference | WEG-10018OP3VFP404TS-W40 |
| Product category | Motor |
| Published specifications | 2 attributes listed |
| Related part numbers | 2 other part numbers in this family |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does 10018OP3VFP404TS-W40 cost?
10018OP3VFP404TS-W40 is listed at CA$7,946.84 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the 10018OP3VFP404TS-W40?
10018OP3VFP404TS-W40 is a WEG part. KKM Solutions sources WEG components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is 10018OP3VFP404TS-W40 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for 10018OP3VFP404TS-W40 — check WEG's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 10018OP3VFP404TS-W40?
Key specifications include Tag: WEG Electric; Weight: 819.0 lb. The full specification table on this page lists every published attribute for this part.
How quickly can 10018OP3VFP404TS-W40 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
Variants & Related Part Numbers
Other WEG part numbers in this family:
- 10018OP3VFP404JPV-W4 — Weg Electric 10018OP3VFP404JPV-W4, 100 Hp, 404/5JP Frame, 1800 RPM, 200/400 Vac, ODP,…
- 10018OP3VFP404TC-W40 — Weg Electric 10018OP3VFP404TC-W40, 100 Hp, 404/5TC Frame, 1800 RPM, 200/400 Vac, ODP,…
