WEG 00736ET3Q213LP-W21 — Motor
Weg Electric, 00736ET3Q213LP-W21, 7.5 Hp, 3600 Rpm, 213LP Frame, 460 Vac, TEFC, 3 PH, Footless, W21 In Line Extra Thrust NEMA Premium Efficiency, 18402485
Overview
Weg Electric, 00736ET3Q213LP-W21, 7.5 Hp, 3600 Rpm, 213LP Frame, 460 Vac, TEFC, 3 PH, Footless, W21 In Line Extra Thrust NEMA Premium Efficiency, 18402485 SPECIFICATIONS Frame 213LP Output 7.5 HP (5.5 kW) Number of Poles 2 Frequency 60 Hz Rated speed 3530 rpm Slip 1.94 % Rated voltage 460 V Rated current 8.67 A L. R. Amperes 60.7 A LRC 7.0x(Code H) No load current 2.50 A Rated torque 11.2 ft.lb Locked rotor torque 200 % Breakdown torque 280 % Locked rotor time 39s (cold) 22s (hot) Moment of inertia (J) 0.4746 sq.ft.lb Design B Insulation Class F Service factor 1.15 Temperature rise 80 K Duty Cycle Cont.(S1) Starting Method Direct On Line Ambient temperature -20°C to +40°C Altitude 1000 m.a.s.l. Degree of Protection IP55 Enclosure IC411 - TEFC Mounting W-6 Rotation¹ Both (CW and CCW) Noise level² 72.0 dB(A) Approx. weight³ 247 lb
Specifications
| Tag | WEG Electric |
|---|---|
| Weight | 247.0 lb |
Product details
| Manufacturer | WEG |
|---|---|
| Manufacturer part number | 00736ET3Q213LP-W21 |
| KKM catalog reference | WEG-00736ET3Q213LP-W21 |
| Product category | Motor |
| Published specifications | 2 attributes listed |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How much does 00736ET3Q213LP-W21 cost?
00736ET3Q213LP-W21 is listed at CA$5,697.09 (CAD) and can be ordered directly from this page with Add to Cart. That figure is a reference price and can change: your card is authorized at checkout and charged only once our order desk confirms the part, stock, and final price, and we email you first if anything has moved. Larger quantities or custom terms — email [email protected] for a volume quote.
Who manufactures the 00736ET3Q213LP-W21?
00736ET3Q213LP-W21 is a WEG part. KKM Solutions sources WEG components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is 00736ET3Q213LP-W21 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for 00736ET3Q213LP-W21 — check WEG's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 00736ET3Q213LP-W21?
Key specifications include Tag: WEG Electric; Weight: 247.0 lb. The full specification table on this page lists every published attribute for this part.
How quickly can 00736ET3Q213LP-W21 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
