Turck PS510-100-04-LI2UPN8-H1141/X
Overview
4-digit, 2-color (red/green), 12-segment display, rotatable by 180° | Housing is rotatable after mounting the process connection | Metal measuring cell | Pressure peak orifice | Pressure range 0…100 bar relative | 18…33 VDC | NO/NC contact, PNP/NPN output, analog output (current/voltage), IO-Link SSP4.1.1 | Process connection G1/4″ male thread | Connector device, M12 × 1
Specifications
| Ambient temperature | -40…+80 °C |
|---|---|
| Approvals | CE, Metrological certification (RUS), cULus |
| Communication Protocol | IO-Link |
| Country of origin | DE |
| Current output | 4…20 mA |
| Design | With display |
| EAN | 4047101541571 |
| Electrical connection | Connector, M12 × 1 |
| Electrical output | Switching output, Current output (3-wire), Voltage output (3-wire), IO-Link |
| Housing material | Stainless-steel/Plastic, 1.4404 (AISI 316L)/Grilamid TR90 UV/Elastollan C 65 A 15 HPM 000/Ultramid A3X2G5 |
| Materials (contact with media) | Stainless steel 1.4404 (AISI 316L)/1.4542 (AISI 630) |
| Medium temperature | -40…+80 °C |
| Operating voltage | 18…33 VDC |
| Pressure range bar | 0…100 bar |
| Pressure range psi | 0…1450.38 psi |
| Pressure type | Relative pressure |
| Process Connection | G 1/4'' male thread |
| Protection class | IP66/IP67/IP69K |
| Voltage output | 0…10 V |
| Weight | 284 g |
Product details
| Manufacturer | Turck |
|---|---|
| Manufacturer part number | 100028686 |
| KKM catalog reference | TURCK-100028686 |
| Product category | Pressure Sensors & Transmitters |
| Published specifications | 20 attributes listed |
| Related part numbers | 16 other part numbers in this family |
