Turck PT250R-2005-U3-H1143/X
Turck 100001253 - Pressure Sensors - Weight: 93 g; Ambient temperature: -30…+85 °C; Housing material: Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0.
Fully welded metal measuring cell | Pressure range 0…250 bar rel. | Pressure peak orifice | 7…33 VDC | Analog output 0…5 V | Process connection 7/16" UNF (SAE) male thread | Plug-in device, M12 × 1
| Ambient temperature | -30…+85 °C |
|---|---|
| Approvals | CE, Metrological certification (RUS), cULus |
| Country of origin | CH |
| Design | Without display |
| EAN | 4047101449877 |
| Electrical connection | Connector, M12 × 1 |
| Electrical output | Voltage output (3-wire) |
| Housing material | Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0 |
| Material pressure transducer | Stainless steel 1.4435 (AISI 316L) |
| Medium temperature | -40…+135 °C |
| Operating voltage | 7…33 VDC |
| Pressure range bar | 0…250 bar |
| Pressure range psi | 0…3625.94 psi |
| Pressure type | Relative pressure |
| Process Connection | 7/16″-20 UNF male thread |
| Protection class | IP67 |
| Voltage output | 0…5 V |
| Weight | 93 g |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for 100001253?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 100001253?
100001253 is a Turck part. KKM Solutions sources Turck components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is 100001253 discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for 100001253 — check Turck's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of 100001253?
Key specifications include Ambient temperature: -30…+85 °C; Approvals: CE, Metrological certification (RUS), cULus; Country of origin: CH; Design: Without display. The full specification table on this page lists every published attribute for this part.
How quickly can 100001253 ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
