StarTech.com ARMPIVOTB — Monitor Mounts & Stands
StarTech.com Desk Mount Monitor Arm for up to 34" (17.6lb/8kg) VESA Compatible Displays - Articulating Pole Mount Single Monitor Arm - Ergonomic Height Adjustable Monitor Mount - Desk Clamp/Grommet
VESA Monitor Mount | Desk/Grommet Mount | Height Adjustable | For up to 17.7lb Monitors
Save desk space and position your monitor for comfortable viewing with this desk-mount monitor arm, made of heavy-duty steel. It features an articulating arm that enables you to tilt, swivel and rotate your screen, to create a more ergonomic workspace and enhance productivity.
Mount your Monitor to Save Valuable Space
The single monitor mount lets you free up space by suspending your display off of your desk. The VESA mount (75x75, 100x100) monitor arm supports a flat-panel display 13" to 34" in size and up to 17.7 lb. (8 kg) in weight.
Rugged Steel Design
With its robust steel construction, the heavy duty monitor arm provides long-lasting performance.
Adjust the Position of your Monitor with Ease
The articulating monitor arm gives you maximum workspace flexibility. You can extend the arm up to 17” (428 mm), swivel 180 degrees and tilt up to 90 degrees to find the perfect viewing angle. The arm offers smooth 360-degree screen rotation, so it’s easy to switch from landscape to portrait position. You can also adjust the height of your monitor along the pole to your desired viewing position, to a maximum height of 17.7" (450 mm).
Easy Installation
The desk clamp monitor mount makes it easy to mount your VESA mount display above your desk, using the included C-clamp or grommet mount. For easier mounting, the VESA mount features notches that let you pre-set the mounting screw, then slide the monitor in place and tighten the screw. To help keep your work area free of clutter, the monitor arm also features cable management clips that keep your cables neatly out of sight.
The ARMPIVOTB is backed by a StarTech.com 5-year warranty and free lifetime technical support.
| Angle of rotation [°] | 360° |
|---|---|
| Cable management | Yes |
| Certification | CE, REACH |
| Clamp included | Yes |
| Compliance certificates | RoHS |
| Depth | 462 mm |
| Grommet base plate included | Yes |
| Grommet plate included | Yes |
| Harmonized System (HS) code | 85299097 |
| Height | 108 mm mm |
| Height adjustment | Yes |
| Housing material | Steel |
| Length | 108 mm ft |
| Manual | Yes |
| Master (outer) case height | 261 mm |
| Master (outer) case length | 384 mm |
| Master (outer) case width | 507 mm |
| Maximum screen size | 68.6 cm (27") |
| Maximum VESA mount | 100 x 100 mm |
| Maximum weight capacity | 8 kg |
| Minimum screen size | 33 cm (13") |
| Minimum VESA mount | 75 x 75 mm |
| Mounting | Clamp |
| Mounting Type | Desk |
| Number of cable clips | 1 |
| Number of displays supported | 1 |
| Number of rubber pads included | 5 pc(s) |
| Number of screws | 9 |
| Number of washers included | 4 |
| Package Depth | 172 mm |
| Package Height | 117 mm |
| Package weight | 3.8 kg |
| Package Width | 485 mm |
| Product colour | Black |
| Products per master (outer) case | 4 pc(s) |
| Screws included | Yes |
| Swivel angle | 180° |
| Tilt angle range | -45 - 45° |
| Weight | 3 kg |
| Width | 160 mm mm |
| Wrench included | Yes |
| Wrench type | Hexagonal wrench |
Request a quote for this part
Email [email protected] or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for ARMPIVOTB?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email [email protected], and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the ARMPIVOTB?
ARMPIVOTB is a StarTech.com part. KKM Solutions sources StarTech.com components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
Is ARMPIVOTB discontinued, and can I still get one?
KKM Solutions does not publish a manufacturer lifecycle status for ARMPIVOTB — check StarTech.com's own product page for whether it is current, superseded, or end-of-life. It does not change what we can do: we source current-production, superseded and long-obsolete parts the same way, and where a part is genuinely unavailable we identify a form-fit-function equivalent. Send the part number through the quote form on this page, or use our obsolete part lookup at https://kkmsolutions.com/tools/obsolete-part-lookup/.
What are the key specifications of ARMPIVOTB?
Key specifications include Angle of rotation [°]: 360°; Cable management: Yes; Certification: CE, REACH; Clamp included: Yes. The full specification table on this page lists every published attribute for this part.
How quickly can ARMPIVOTB ship?
In-stock items are dispatched the same business day for orders placed by 11 AM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
