Siemens 32SB1600 Rating Plug 1600A for SB Series Circuit Breakers with 3200A Sensor

Description The Siemens 32SB1600 rating plug is a precision accessory designed to define the current rating of compatible SB series circuit breakers. Rated at 1600 A, it operates with a 3200 A sensor to ensure accurate trip unit calibration and system protection. This component enables reliable configuration of breaker performance in high-capacity power distribution systems. Technical Specifications Condition New/Never Used Surplus Brand Siemens Category Circuit Breaker Accessories Part Number 32SB1600 Subcategory Rating Plugs Series SB Series Type 32SB Rated Current 1600 A Sensor Rating 3200 A Compatible Frames SBA, SBH, SBS Trip Unit Compatibility SB-EC, TL electronic trip units Function Current rating configuration Installation Type Plug-in Application Industrial power distribution systems Weight 3.00 lbs (≈ 1.36 kg) Information About 32SB1600 The 32SB1600 is part of Siemens’ SB series rating plug range, developed for use with insulated case circuit breakers in demanding industrial environments. It is a fixed rating plug element that establishes the continuous current rating of breakers equipped with SB-EC or TL electronic trip units. Designed for compatibility with SBA, SBH, and SBS frame breakers, it supports systems utilizing 3200 A frame sizes. This component is widely applied in heavy-duty electrical distribution systems where precise current control and protection coordination are essential. Key Features: Current Rating Configuration: Sets breaker trip unit rating to 1600 A for accurate protection Sensor Compatibility: Designed for use with 3200 A sensor systems SB Series Integration: Compatible with Siemens SBA, SBH, and SBS breaker frames Electronic Trip Unit Support: Works with SB-EC and TL solid-state trip units Fixed Rating Design: Provides stable and consistent current calibration Plug-In Installation: Allows easy replacement and configuration without system modification High-Capacity Application: Suitable for industrial power distribution environments The 32SB1600 delivers the reliability and precision required for accurate current setting and protection configuration in high-capacity circuit breaker systems.
