Sealmaster CRPS-PN32T RMW — Mounted Ball Bearings
Sealmaster CRPS-PN32T RMW - Mounted Ball Bearings - Bearing Type: Standard Duty; Weight: 9.70; Certifications: IP69K.
The Sealmaster CRPS-PN32T RMW is part of the Mounted Ball Bearings range in our industrial catalog. The manufacturer's published data for this part number specifies Bearing Type: Standard Duty and Weight: 9.70.
Published specifications for this part include Certifications: IP69K; Housing material: Stainless Steel; Options: Corrosion Resistant - Reduced Maintenance - Lubed for Life; Housing Style: Pillow Block; UPC: 662461388457; Bore Shape: Straight; Rolling Element: Ball Bearing; Overall Width (in): 2.38 in; Bolt Size (in): 5/8 in; Housing Construction: One Piece; Overall Height (in): 5.00 in; Overall Length (in): 8.63 in. See the Specifications tab on this page for the full technical table.
| Ability to Relubricate | No |
|---|---|
| Base Length (in) | 8.63 in |
| Base to Center Height (in) | 2.5000 in |
| Base Width (in) | 2.38 in |
| Bearing Insert Finish | Phosphorus Nickel Coated |
| Bearing Insert Material | 52100 Bearing Steel |
| Bearing Type | Standard Duty |
| Bolt Size (in) | 5/8 in |
| Bolt Spacing Max (in) | 7 in |
| Bolt Spacing Min (in) | 6.5 in |
| Bore Diameter (in) | 2 in |
| Bore Shape | Straight |
| Cage Material | PPS - Polyphenylene Sulfide |
| Cage Type | Land Riding Retainer |
| Centerline to Outermost Bearing Face (in) | 1.313 in |
| Certifications | IP69K |
| Dynamic Load Rating (lb) | 9,752 lb |
| End Cap Available | Yes |
| Fixed vs. Expansion | Fixed |
| Foot Height (in) | 0.75 in |
| Grease Fitting Thread Size | 1/8 NPT |
| Housing Base | Solid |
| Housing Color | Silver |
| Housing Construction | One Piece |
| Housing material | Stainless Steel |
| Housing Style | Pillow Block |
| Housing Type | Pillow Block, Two Bolt |
| Inner Race Heat Treat Method | Zone-Hardened |
| Inner Ring Outside Diameter (in) | 2.719 in |
| Insert | PN-32T |
| Length Through Bore (in) | 2.19 in |
| Locking Collar Outside Diameter (in) | 3.50 in |
| Lubricant | Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease |
| Max Operating Temperature (F) | 220 °F |
| Maximum Speed (RPM) | 1350 rpm |
| Misalignment Capability | ±2.0° Misalignment - Static Only |
| Misalignment Type | Static Only |
| Options | Corrosion Resistant - Reduced Maintenance - Lubed for Life |
| Outer Ring Land Profile | Tapered Lands |
| Overall Height (in) | 5.00 in |
| Overall Length (in) | 8.63 in |
| Overall Width (in) | 2.38 in |
| Radial Clearance | Standard |
| Rolling Element | Ball Bearing |
| Seal Type | Multi-Lip Contact Seal |
| Shaft Locking Type | Concentric |
| Size Code | 2-23 |
| Static Load Rating (lb) | 6,601 lb |
| UPC | 662461388457 |
| Vibration Frequency Fundamental Train | 0.0068 cps |
| Vibration Frequency Inner Ring Defect | 0.0987 cps |
| Vibration Frequency Outer Ring Defect | 0.068 cps |
| Vibration Frequency Roller Spin | 0.0437 cps |
| Weight | 9.70 |
