Schunk ROTA TP 315-105 Z235-SV90°
Schunk 816150 - Pneumatic power lathe chucks - Weight (Kg): 78.0; Spindle Type: -; Max Operating Pressure (bar): 8.0.
Schunk 816150 is a Pneumatic power lathe chucks catalog item from Schunk. The manufacturer's published data for this part number specifies Weight (Kg): 78.0 and Spindle Type: -.
The specification set recorded for this part number covers Max Operating Pressure (bar): 8.0; Min. operating pressure [bar]: 3.0; Spindle size: Z235; Serration: 1/16" x 90°; Stroke/jaw [mm]: 5.0; Moment of inertia [kgm²]: 1.13; Max. clamping force (at 6 bar) [kN]: 100.0; Air consumption/jaw stroke at 6 bar [l]: 8.0; Opening/closing time [s]: 5.0; Max. RPM 1 [1/min]: 2200.0; Max. RPM 2 [1/min]: 3000.0. See the Specifications tab on this page for the full technical table.
| Air consumption/jaw stroke at 6 bar [l] | 8.0 |
|---|---|
| Max Operating Pressure (bar) | 8.0 |
| Max. clamping force (at 6 bar) [kN] | 100.0 |
| Max. RPM 1 [1/min] | 2200.0 |
| Max. RPM 2 [1/min] | 3000.0 |
| Min. operating pressure [bar] | 3.0 |
| Moment of inertia [kgm²] | 1.13 |
| Opening/closing time [s] | 5.0 |
| Serration | 1/16" x 90° |
| Spindle size | Z235 |
| Spindle Type | - |
| Stroke/jaw [mm] | 5.0 |
| Weight (Kg) | 78.0 |
Frequently Asked Questions
How do I get pricing for 816150?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 816150?
816150 is a Schunk part. KKM Solutions sources Schunk components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 816150?
Key specifications include Air consumption/jaw stroke at 6 bar [l]: 8.0; Max Operating Pressure (bar): 8.0; Max. clamping force (at 6 bar) [kN]: 100.0; Max. RPM 1 [1/min]: 2200.0. The full specification table on this page lists every published attribute for this part.
How quickly can 816150 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
