Schunk FUS-211B
Schunk 320528 - Compensation units - Weight (Kg): 0.5; Diameter D [mm]: 99.1; Max Operating Pressure (bar): 6.0.
This listing covers the Schunk 320528, a part number in the Compensation units category. The manufacturer's published data for this part number specifies Weight (Kg): 0.5 and Diameter D [mm]: 99.1.
The specification set recorded for this part number covers Max Operating Pressure (bar): 6.0; Min. operating pressure [bar]: 5.0; Min. ambient temperature [°C]: 5.0; Max. ambient temperature [°C]: 60.0; Repeat accuracy [mm]: ± 0.026; Height Z [mm]: 45.0; Moment Mx max. [Nm]: 7.3; Moment My max. [Nm]: 7.3; Locking: with locking; Compensation XY* [mm]: 2.2; Angular deflection [°]: 1.1; Max. force Fd [N]: 1400.0. The complete technical table is shown in the Specifications tab on this page.
| Angular deflection [°] | 1.1 |
|---|---|
| Compensation center distance [mm] | 150.0 |
| Compensation XY* [mm] | 2.2 |
| Diameter D [mm] | 99.1 |
| Height Z [mm] | 45.0 |
| Locking | with locking |
| Locking force Fz [N] | 53.0 |
| Max Operating Pressure (bar) | 6.0 |
| Max. ambient temperature [°C] | 60.0 |
| Max. force Fd [N] | 1400.0 |
| Max. force Fx/Fy horizontal installation [N] | 8.9 |
| Max. force Fx/Fy vertical installation [N] | 53.0 |
| Min. ambient temperature [°C] | 5.0 |
| Min. operating pressure [bar] | 5.0 |
| Moment Mx max. [Nm] | 7.3 |
| Moment My max. [Nm] | 7.3 |
| Repeat accuracy [mm] | ± 0.026 |
| Rigidity shift [N/mm] | 11.0 |
| Rotary compensation angle [°] | 4 |
| Weight (Kg) | 0.5 |
Frequently Asked Questions
How do I get pricing for 320528?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 320528?
320528 is a Schunk part. KKM Solutions sources Schunk components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 320528?
Key specifications include Angular deflection [°]: 1.1; Compensation center distance [mm]: 150.0; Compensation XY* [mm]: 2.2; Diameter D [mm]: 99.1. The full specification table on this page lists every published attribute for this part.
How quickly can 320528 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
