216504 — Schunk TENDO Turn DSE Ø20 Ø12x48
KKM Solutions is an independent parts distributor, not an authorized Schunk dealer — how we source.
Schunk 216504 - TENDO hydraulic expansion toolholder - Series: TENDO Turn; Technology: Hydraulic expansion toolholder; g: M8x1.
Overview
Part number 216504 from Schunk, listed in Hydraulics. Specifications on file: Clamping diameter D1 12 mm; Coolant-proof yes; D3 [mm] 53.0; D5 [mm] 20.0. KKM Solutions quotes this part with pricing and availability confirmed per order.
In our catalog, the 216504 from Schunk is listed under the TENDO hydraulic expansion toolholder category. The manufacturer's published data for this part number specifies Series: TENDO Turn and Technology: Hydraulic expansion toolholder.
The specification set recorded for this part number covers g: M8x1; Weight (Kg): 0.4; Min torque (Nm): 65.0; D3 [mm]: 53.0; Toolholder interface: DSE; Clamping diameter D1: 12 mm; D6 [mm]: 23.4; Projecting length L1 [mm]/[inch]: 16 mm / 0.6"; L2 [mm]: 46.0; L3 [mm]: 10.0; L4 [mm]: 3.5; Coolant-proof: yes. The complete technical table is shown in the Specifications tab on this page.
Specifications
| Clamping diameter D1 | 12 mm |
|---|---|
| Coolant-proof | yes |
| D3 [mm] | 53.0 |
| D5 [mm] | 20.0 |
| D6 [mm] | 23.4 |
| g | M8x1 |
| L [mm] | 64.0 |
| L2 [mm] | 46.0 |
| L3 [mm] | 10.0 |
| L4 [mm] | 3.5 |
| Min torque (Nm) | 65.0 |
| Projecting length L1 [mm]/[inch] | 16 mm / 0.6" |
| Series | TENDO Turn |
| Standard length | yes |
| Technology | Hydraulic expansion toolholder |
| Toolholder interface | DSE |
| Weight (Kg) | 0.4 |
Product details
| Manufacturer | Schunk |
|---|---|
| Manufacturer part number | 216504 |
| Product category | Hydraulics |
| Published specifications | 17 attributes listed |
| Related part numbers | 3 other part numbers in this family |
Request a quote for this part
Email orderdesk@kkmsolutions.com or call (825) 454-5367 for pricing and availability.
Frequently Asked Questions
How do I get pricing for 216504?
This part is quoted on request, so no price is listed for it here. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 216504?
216504 is made by Schunk and is listed in our Hydraulics category. KKM Solutions is an independent distributor, not an authorized Schunk dealer: we source the exact Schunk part number 216504, and the quote confirms condition and lead time before you order.
Is the 216504 new and genuine?
Parts we supply are new and genuine unless the quote expressly states otherwise. Where a part is new-old-stock, from excess inventory, refurbished or open-box, the quote says so before you approve it.
What warranty comes with the 216504, and can I return it?
Parts we supply are warranted against manufacturing defects for 1 year from the date of delivery; where the manufacturer's own warranty is longer, the manufacturer's warranty applies. The warranty covers repair, replacement, or credit of the defective part and does not cover normal wear items, misapplication, improper installation, or consequential damages. Contact us within 30 days of delivery before returning anything — all returns need a return authorization from the order desk.
What is the lifecycle status of 216504?
No published lifecycle status is on file for 216504. Schunk lists whether a catalog number is current, superseded or end-of-life on its own product page, and our order desk confirms the status with the manufacturer at quote time, before you commit. Send the part number through the quote form on this page.
What are the key specifications of 216504?
Key specifications include Clamping diameter D1: 12 mm; Coolant-proof: yes; D3 [mm]: 53.0; D5 [mm]: 20.0. The full specification table on this page lists every published attribute for this part.
How much does 216504 weigh?
Per the published specification for 216504: Weight (Kg): 0.4. Confirm against the full specification table on this page, or ask our order desk to verify it with the manufacturer at quote time.
How quickly can 216504 ship?
Lead time for 216504 is quoted per order and confirmed on your quote, which our order desk sends within 1 business day. For a line-down emergency, call the 24/7 order desk at (825) 454-5367.
