Schunk KSP3 64
Schunk 1409254 - Pneumatic clamping force blocks - Weight (Kg): 1.5; Max Operating Pressure (bar): 9.0; Stroke per jaw [mm]: 2.0.
Schunk 1409254 is a Pneumatic clamping force blocks catalog item from Schunk. The manufacturer's published data for this part number specifies Weight (Kg): 1.5 and Max Operating Pressure (bar): 9.0.
The specification set recorded for this part number covers Stroke per jaw [mm]: 2.0; Min. operating pressure [bar]: 2.0; Clamping force at max. operating pressure [kN]: 4.5; Repeat accuracy of vise [mm]: 0.01; Max. jaw height [mm]: 60.0; Air consumption per double stroke at 6 bar [cm³]: 220.0; Distance H [mm]: 10.0; Closing/opening time [s]: 0.1. The complete technical table is shown in the Specifications tab on this page.
| Air consumption per double stroke at 6 bar [cm³] | 220.0 |
|---|---|
| Clamping force at max. operating pressure [kN] | 4.5 |
| Closing/opening time [s] | 0.1 |
| Distance H [mm] | 10.0 |
| Max Operating Pressure (bar) | 9.0 |
| Max. jaw height [mm] | 60.0 |
| Min. operating pressure [bar] | 2.0 |
| Repeat accuracy of vise [mm] | 0.01 |
| Stroke per jaw [mm] | 2.0 |
| Weight (Kg) | 1.5 |
Frequently Asked Questions
How do I get pricing for 1409254?
KKM Solutions is a quote-based industrial supplier, so prices are not listed online. Send the quote form on this page with your quantity, or email orderdesk@kkmsolutions.com, and our order desk will reply with pricing and availability within 1 business day.
Who manufactures the 1409254?
1409254 is a Schunk part. KKM Solutions sources Schunk components to the exact manufacturer specification and cross-checks every order against manufacturer part data before it ships.
What are the key specifications of 1409254?
Key specifications include Air consumption per double stroke at 6 bar [cm³]: 220.0; Clamping force at max. operating pressure [kN]: 4.5; Closing/opening time [s]: 0.1; Distance H [mm]: 10.0. The full specification table on this page lists every published attribute for this part.
How quickly can 1409254 ship?
In-stock items are dispatched the same business day for orders placed by 3 PM; sourced and quoted items ship per the quoted lead time. KKM Solutions ships worldwide — to your site, warehouse, or freight forwarder.
