Omron R88M-G20030H-S2-Z | Omron 200W AC Servo Motor

Description The Omron R88M-G20030H-S2-Z is a 200 W AC servo motor designed for high-accuracy motion tasks in compact automation setups. Operating on 200 VAC single-phase input, it delivers high-speed output and precise positioning with the help of an incremental encoder. Technical Specifications Condition New/Never Used Surplus Brand Omron Category Motors Part Number R88M-G20030H-S2-Z Subcategory AC Servo Motors Series R88M G-series Motor Type Cylindrical Servo Motor Rated Output Power 200 W Rated Voltage 200 VAC Phase Single Phase Rated Current 1.6 A Maximum Current 4.9 A Rated Torque 0.64 Nm Peak Torque 1.78 Nm Maximum Speed 5000 rpm Encoder Type Incremental Encoder (10,000 pulses) Shaft Configuration Straight, Keyed, Tapped Mounting Type Flange-mounted Termination Style Cable with Circular Connector Cooling Method Totally enclosed, self-cooling Vibration Resistance 49 m/s² Operating Temperature 0°C to 40°C Approvals CSA, UL Weight 1.8 lbs (816.5 g) Information About R88M-G20030H-S2-Z The R88M-G20030H-S2-Z is part of the G-series servo motor family from Omron, known for its compact build and advanced response performance. This model features a cylindrical, flange-mounted structure with a 60 mm square face and straight keyed shaft, supporting a maximum speed of 5000 rpm. With a 10,000 ppr incremental encoder, it enables reliable closed-loop control in demanding applications such as pick-and-place systems, robotic joints, or precision conveyors. Its rugged self-cooling enclosure and CSA/UL approvals make it a trusted solution in regulated industrial automation environments. Key Features Compact High-Speed Motor : Delivers up to 5000 rpm while maintaining positional stability in compact control systems. Accurate Position Feedback : Integrated 10,000 pulse/rev incremental encoder enables precise real-time motion control. Torque Stability Under Load : Offers rated torque of 0.64 Nm and peak torque of 1.78 Nm for high-load fluctuation tolerance. Industrial Voltage Operation : Operates on 200 VAC single-phase with 1.6 A rated and 4.9 A peak current for consistent drive performance. Durable Mechanical Integration : Straight keyed and tapped shaft allows for rigid coupling with drive mechanisms and precise mechanical alignment. Reliable Flange Mounting : Square 60 mm face with 70 mm bolt spacing provides structural stability during high-speed motion. Thermal and Mechanical Protection : Features a fully enclosed, self-cooling casing designed to manage internal heat and resist vibration. Regulatory Compliance : Certified by UL and CSA for integration into safety-conscious machine designs. The R88M-G20030H-S2-Z delivers the reliability and precision required for servo applications demanding tight control and compact configuration.
